Tech Controllers EU-T-5z WiFi User Manual page 11

➢ MAIN SCREEN DESCRIPTION - ZONE 1 SCREEN
1
1. WiFi signal range
2. Current date
3. Current time
4. Pre-set temperature in the given zone
5. Duration of the pre-set temperature (time overlay)
6. Additional device icon – If visible, this means that the device is switched on
7. Current room temperature.
➢ MAIN SCREEN DESCRIPTION – WIFI SCREEN VIEW
1
5
1. Day of the week
2. Current date
3. Current time
4. Signal strength
5. Name of the selected WiFi network.
2 3
7
2
11
6
3
4
5
4
