a) If the value is still 0.0.0.0 / -.-.-.-.- , check the network settings or the Ethernet connection between the Inter-
net module and the device.
7. After the IP address has been assigned, start the module registration in order to generate a code which must be
assigned to the account in the application.
•
WIFI NETWORK SELECTION
Once you enter this submenu, the controller displays the list of available networks. After selecting the network to
connect to, accept the selection by pressing the MENU button. If the network is secured, it is necessary to enter a
password – use the "+" and "-" buttons to select the next letters of the password. Once the password is typed in, press
EXIT.
•
NETWORK CONFIGURATION
The standard network configuration runs automatically. However, if the user wishes to manually configure the network,
they can do so using the following sub-menu options: DHCP, IP address, Subnet mask, Gateway address, DNS address,
and MAC address.
•
REGISTRATION
By running the Registration option, we generate the code required to register the EU-T-5z WiFi at https://emodul.eu -
please refer to the First start-up section.

7.2. PROTECTIONS

This function is used to change the settings of the parental lock. When the "Time Lock" function is activated, the screen
will lock after the time set in the "Lock Time" option. The user can set their access PIN to the controller menu.
NOTE
The factory default PIN is '0000'.

7.3. TIME SETTINGS

The current time and date are automatically downloaded from the network. The user can set the date and time
manually.

7.4. SCREEN SETTINGS

The parameters of this submenu allow you to adjust the appearance of the main screen of the controller to individual
needs. The user can change the data displayed on the controller screen: Wi-Fi (the screen displays the name of the
connected network and signal strength) or Zone (current and set values in the zone).
You can also adjust the contrast and brightness of the display. Thanks to the Screen blanking function, it is possible to
set the screen brightness during fading. The Screen blanking time option allows you to set the idle time, after which the
controller will go into the screen blanking state.

7.5. LANGUAGE SELECTION

The function allows you to change the controller language version.

7.6. SERVICE MENU

The parameters of this submenu are intended for people with appropriate qualifications and are protected by a code.
18
