- Page 1 ANT-37100 / ANT-37500 / ANT-37500W QUICK START GUIDE 16 Channel Decoder - 4K & 1080P Multi-Display Decoder Antrica Quick Start Guide ANT-37XXX Series V1_2022 Page 1...
-
Page 2: Table Of Contents
7.0 Network settings 8.0 Display: (setting up the monitor resolution and OSD sizes) 9.0 System: Firmware upgrade, saving Configs and more) 10.0 Logout screen 11.0 Remote control (Using the IR remote supplied) Antrica Quick Start Guide ANT-37XXX Series V1_2022 Page 2... -
Page 3: Whats In The Box
The ANT-37XXX will take approximately 1 minute to boot up. You will see an ANTRICA logo appear on screen followed by an empty quad view. For a few seconds the IP address of the ANT-37XXX will appear plus firmware version. If network is unplugged it will say No NETWORK. - Page 4 NOW and the bottom one defines what display you want to be default after a reboot or power up. To start adding cameras or encoders please go to the DISCOVER tab (Sec 5.0) Antrica Quick Start Guide ANT-37XXX Series V1_2022 Page 4...
-
Page 5: Add An Rtsp Url
RTSP Step 2: At the bottom of this page you will see the camera appear in your list; RTSP Step 3:Save the RTSP by clicking SAVE RTSP Step 4: Repeat for as many RTSP cameras as you want to add Antrica Quick Start Guide ANT-37XXX Series V1_2022 Page 5... -
Page 6: Add An Onvif Camera
Username and Password boxes as shown below. Step 3: Add user and password details for your selected camera, click ADD The added ONVIF camera now appears at the bottom of this web page click Query Antrica Quick Start Guide ANT-37XXX Series V1_2022 Page 6... -
Page 7: Cameras (Setting Up Different Views And Choosing Camera)
This section allows you to setup your display preferences once all cameras have been added manually or via ONVIF discovery in section 5.0 As this is quite a detailed section we have listed the columns and headings below as a simple list. Antrica Quick Start Guide ANT-37XXX Series V1_2022 Page 7... - Page 8 Setup network parameters: Default IP is 192.168.0.222 Static Address : IP address of this Decoder Gateway: Router Gateway IP Netmask: Number of subnet IP block addresses visible DNS: DNS server IP address NTP: NTP clock server IP address Antrica Quick Start Guide ANT-37XXX Series V1_2022 Page 8...
- Page 9 System Restart: Either Reboot or do a Factory reset and erase all settings to default. Enable HTTPS: allow secure https access Load SSL Keys; Choose and load the SSL key and certificate . Antrica Quick Start Guide ANT-37XXX Series V1_2022 Page 9...
-
Page 10: Remote Control (Using The Ir Remote Supplied)
The up down left right to toggle between 1x1 2x2 3x3 4x4 modes. After selecting a 1x1 view the left right buttons will toggle through full screen views. ANT-37100 ANT-37500 Remote Remote Antrica Quick Start Guide ANT-37XXX Series V1_2022 Page 10... - Page 11 Please visit our website www.antrica.com and browse to the product page (e.g ANT-37100 ANT-37500) where you can find a DOWNLOADS SECTION : Or in the main web page there is a DOWNLOADS section to find: application notes Full User manuals...
- Page 12 Antrica Quick Start Guide ANT-37XXX Series V1_2022 Page 12...
