Antrica ANT-6000E Specification & User Manual

Ant-6000 series full hd decoder
Hide thumbs

Advertisement

Quick Links

Download this manual
ANT-6000X
Specification & User Manual
Version 1.5
October, 2012
This document is confidential
and
subject to change

Advertisement

loading
Need help?

Need help?

Do you have a question about the ANT-6000E and is the answer not in the manual?

Questions and answers

Related Manuals for Antrica ANT-6000E

Summary of Contents for Antrica ANT-6000E

  • Page 1 ANT-6000X Specification & User Manual Version 1.5 October, 2012 This document is confidential subject to change...
  • Page 2 ANT-6000X (ANT-6000E & ANT-6000D) ANT-6000E ANT-6000E ANT-6000D ANT-6000D Front view Rear view Front view Rear view Details subject to change and Firmware version...
  • Page 3 ANT-6000X - Connection HD-SDI HD-SDI HDMI HDMI D-sub D-sub Ethernet Multimedia Player TV or Monitor ANT-6000E ANT-6000D Details subject to change and Firmware version...
  • Page 4 ANT-6000X (ANT-6000E/ANT-6000D) Main Highlights   1080p60 full HD encode/decode with H.264 Baseline Profile (Level 4.2) •  Supports both interlacing and progressive input streams   Very low encode/decode latency •  Latency of encode-decode in 1080p60 HD: 90 ms   PC2TV: Supports both DTV & VESA Standards • ...
  • Page 5 Encoder (ANT-6000E)   Video Input •  HDMI(DVI): up to 1080p60, HDMI v1.3 compatible •  RGB (D-Sub): VESA formats up to 1280 x 1024 and 1920 x 1080p60 •  HD-SDI & 3G-SDI: up to 1080i60/p60   Audio Input •  HDMI : HDMI compatible audio, Compressed or Uncompressed • ...
  • Page 6 Decoder (ANT-6000D)   Video Output •  HDMI: up to 1080p60, HDMI v1.3 compatible •  RGB (D-Sub): VESA formats up to 1280 x 1024 and 1920 x 1080p60 •  HD-SDI & 3G-SDI: up to 1080i60/p60 •  COMPONENT (YPbPr) (using gender): All HDTV formats up to 1080i60  ...
  • Page 7 Video Format Supported: VESA & DTV Video Standard Resolutions HDMI D-SUB COMP 640 x 480P 60/70/72/75/85 800 x 600P 56/60/72/70/75/85 1024 x 768P 60/70/72/75/85 1152 x 864P 60/70/75/85 1280 x 800P 60 1280 x 960P 60/70/72/75/85 1280 x 1024P 60/70/75/85 PC Format 1360 x 768P 60 (VESA or Industrial)

  • Page 8: Common Specifications

    Common Specifications Video Compression H.264 Baseline Profile Level 4.2 Video Resolutions (partial list) 480i/p, 720p, 1080i and 1080p (24fps/30fps/60fps) System Latency Less than 90 millisecond Delay between Transmitter and Receiver Ethernet LAN 10/100 BASE-Encoder, car.5e UTP cable Optional: PoE (Max. power 13W) Upgrade SW firmware Optional: 3G/LTE wirless network Power Supply...
  • Page 9 ANT-6000E/D specification ANT-6000E spec 1 x HDMI HDMI-v1.3 compatible, Up to 24 bit RGB or YUV (4:2:2) Digital Video IN Interface 1 x HD-SDI Female BNC, 3G-SDI(2.970Gb/s), HD-SDI(1.485Gb/s), SD-SDI(270Mb/s) Analog Video IN Interface 1 x D-Sub (15pin) RGB Video with D-Sub, YPbPr with D-Sub to component gender...
  • Page 10 ANT-6000E/D Video Outputs HDMI Analog Output Mode (HDMI Colour space) YPbPr Audio Video Audio Video Audio Colour HDMI (RGB) No Out mismatch Colour HDMI (YPbPr) mismatch DSUB No Out No Out No Out Colour Component mismatch Colour HDSDI mismatch Details subject to change and Firmware version...
  • Page 11 Boards of Encoder (ANT-6000E)/Decoder (ANT-6000D) Decoder Encoder Audio +12.0V +12.0V Audio HDMI HDMI POWER POWER RS-2 Back Ch. RS-2 Back Ch. D-Sub D-Sub HD-SDI HD-SDI Audio Audio Details subject to change and Firmware version...
  • Page 12 ANT-6000X Front LED & Rear Connector Details subject to change and Firmware version...

  • Page 13: Led Description

    LED Description ANT-6000E Blinking Power Power on Power off Link Link up status and data transmit HD-SDI Selected and input normal Not Selected Selected and No input HDMI Selected and input normal Not Selected Selected and No input Selected and input normal...
  • Page 14 LED operation at booting ANT-6000E Link LED Video Port LED (HD-SDI, HDMI, RGB) Time Power LED ON Blinking 3 x LED Blinking 4~5sec Blinking LED Off 40~45sec Booting Blinking Blinking 60~65sec Normal operation Fast Blinking LED On 90~95sec ANT-6000D Link LED...

  • Page 15: Factory Reset

      All LEDs except power LED will blink fast, then you can release the button.   It will reboot after 2~3 minutes.   The IP address will be set to default value of 192.168.0.161 for ANT-6000E, and 192.168.0.162 for ANT-6000D.
  • Page 16 Web Based Interface   System Configuration   Serial port Configuration   FW Images   Streaming Control   Save changes   Reboot System Details subject to change and Firmware version...

  • Page 17: System Configuration

    System Configuration Details subject to change and Firmware version...
  • Page 18 Changing IP address of the ANT-6000E or ANT-6000D   Default IP address of the ANT-6000E and ANT-6000D were set to 192.168.0.161 for ANT-6000E (Encoder) and 192.168.0.162 for ANT-6000D (Decoder). So, if this IP address is used by other IP devices on the same network, then you have to change the IP address to another one through the web interface of the Encoder and Decoder.
  • Page 19 System Configuration (Encoder) Ethernet Configurations Streaming Mode : P2P/Multicast Multicast address when Multicast mode Peer address when P2P mode Click ‘Submit’ to activate the changes of Configuration Count value for Multicast Time To Live Click ‘Refresh’ to display current status ANT-6000X Details subject to change and Firmware version...
  • Page 20 System Configuration (Encoder) – P2P mode Select P2P Enter Peer address ANT-6000X Details subject to change and Firmware version...
  • Page 21 System Configuration (Encoder) – Multicast mode Select Muticast Enter multicast address ANT-6000X Details subject to change and Firmware version...
  • Page 22 System Configuration (Decoder) Ethernet Configurations Streaming Mode : P2P/Multicast Multicast address when Multicast mode Peer address when P2P mode Click ‘Submit’ to activate the changes of Configuration Click ‘Refresh’ to display current status ANT-6000X Details subject to change and Firmware version...
  • Page 23 System Configuration (Decoder) – P2P mode Select P2P Enter Peer address ANT-6000X Details subject to change and Firmware version...
  • Page 24 System Configuration (Decoder) – Multicast mode Select Muticast Enter multicast address ANT-6000X Details subject to change and Firmware version...

  • Page 25: Serial Port Configuration

    Serial Port Configuration Baud rate Stop Bit Character Parity 1200 size Disable 2400 4800 Even 9600 19200 38400 115200 ANT-6000X Details subject to change and Firmware version...
  • Page 26 Firmware Images Also referred to as FW or S/W Details subject to change and Firmware version...
  • Page 27 FW Images (S/W) Information about currently working FW Information about FW on Flash ROM Information about newly downloaded FW on RAM These two buttons are shown only when there is newly downloaded FW and it is different to currently working FW Download from Server or upload from local PC Click ‘Refresh’...
  • Page 28 FW Images – Download from Remote Server Step 1. Enter the url address of FW image (FW) if you want to download server’s file into ANT-600 http://192.168.0.12/ANT-6000X_ver_antrica.100.15.img tftp://192.168.0.12/ANT-6000X_ver_antrica.100.15.img ftp://user:passwd@192.168.0.12/ANT-6000X_ver_antrica.100.15.img Step 2. Caution: In above example, corresponding server(http, tftp or ftp) must be running on 192. Click <Download>...
  • Page 29 FW upgrade – Upload from Local PC Step 1 Click this button and select a FW image file that will be upl Step 2. oaded from the local PC Click <Upload> button Step 3. Click <Write To Flash> button to adapt newly transferred into ANT-6000X.

  • Page 30: Streaming Control

    Streaming Control Details subject to change and Firmware version...
  • Page 31 Streaming Control (Encoder) Peer Machine Status Select video/audio input port Input A/V Status Streaming Status Click to restart A/V part Packetizing & Server Control Video Encoding & Streaming Control Click ‘Submit’ to activate the changes of Configuration Audio Streaming Control Click ‘Refresh’...
  • Page 32 Streaming Control (Encoder) : Video Encoding & Streaming Control This button click causes forcing one I-frame regardless current m Encapsulation : RTP / TS2UDP ode RTSP Server : On/Off Video streaming : On/Off Coding Mode : GOP/RandIntraCoded/ContIntraCoded Intra Count : number of P-frame s which an I frame is spread into GOP size : gap between two I-frames set range : 60 ~ 65535...
  • Page 33 Streaming Control (Encoder) : Audio Streaming Control Audio Streaming : Stereo / Mono / Off PCM Compress : None / aLaw / uLaw PCM 8KHz DownSample: On/ Off Audio Direction : All / Decoder / RTSP ANT-6000X Details subject to change and Firmware version...
  • Page 34 Bandwidth for Audio in ANT-6000X   When input audio is linear PCM (no compression), the audio bitrate can be changed through th e selection of “Audio Streaming”, “PCM compress” or “PCM 8KHz DownSample” fields.   When audio input is PCM 48KHz, audio bitrate is about 1,536kbps. • ...
  • Page 35 Streaming Control (Encoder) - RTP mode without RTSP Server Notice This mode is for a working condition only between ANT-6000X Encoder and Decoder. Select RTP Select Off We recommend randIntraCoded Select On at Coding Mode and value 120 of IntraCount. Must not select RTSP for this mo We recommend Decoder than All Details subject to change and Firmware version...
  • Page 36 Streaming Control(Encoder) - RTP mode with RTSP Server Notice This mode is for ANT-6000D Decoder and RTSP client. When in P2P mode, ANT-6000E Enc oder can serve max 4 clients including a ANT-6000D Decoder. Available number of clients depends on CBR setting.
  • Page 37 (IPTV set-top compatible) Notice In this mode, ANT-6000D Decoder and RTSP client cannot receive stream from this ANT-6000X Encoder and ANT-6000E Encoder does not str eam audio in this mode. Select TS2UDP Select On Select GOP Details subject to change and Firmware version...
  • Page 38 Streaming Control (Decoder) Peer Machine Status Video output port HDMI / DSUB / COMPONENT / HDSDI COMPONENT using Gender Click to restart receiver HDMI ColourSpace : RGB/YPbPr Video output control Input or particular resolution Back Channel Audio Control Click ‘Refresh’ to display current st Click ‘Submit’...
  • Page 39 ANT-6000X – Back channel audio connection TV or Monitor HD-SDI HD-SDI Multimedia HDMI HDMI Player D-sub D-sub Ethernet External Audio source ANT-6000E ANT-6000D Details subject to change and Firmware version...

  • Page 40: Save Changes

    Save Changes Click this button to save the changes of configuration ANT-6000X Details subject to change and Firmware version...
  • Page 41 Reboot the system : Click the Reboot Button Click this button to reboot the Transmitter ANT-6000X Details subject to change and Firmware version...
  • Page 42 RTSP client : in a VLC media player 1. Select <Media>– <Open Net work Stream> 2. Enter RTSP stream address Ex) rtsp://192.168.0.233:8554/stream 3. Click play button Details subject to change and Firmware version...
  • Page 43 RTSP client : in a VLC media player Details subject to change and Firmware version...
  • Page 44 TS2UDP client : in a VLC media player 1. Select <Media>– <Open Net work Stream> 2. Enter legacy udp stream When Encoder is in P2P mode udp://@:1234/ When Encoder is in multicast mode udp://@227.2.2.7:1234/ 3. Click play button Details subject to change and Firmware version...
  • Page 45 TS2UDP client : in a VLC media player Details subject to change and Firmware version...
  • Page 46 8 Hasting Close Bray, Berkshire SL6 2DA United Kingdom tel: +44 1628 626098 sales@antrica.com www.antrica.com Details subject to change and Firmware version...

This manual is also suitable for:

Ant-6000d
