- Page 1 ANT-7000 QUICK START GUIDE Applicable to ANT-7000 (ANT-7000E & ANT-7000D) Low Latency (30mS) Encoder Decoder with KVM Function Contents 1 Whats in the box 2 Setting up the ANT-7000E & ANT-7000D 3. Configuring the ANT-7000E Encoder 3.1 System Configuration 3.2 Streaming Control 3.3 Reboot System...
- Page 2 1.What’s in the Box The ANT-7000 Encoder and Decoder box contains - ANT-7000E encoder -ANT-7000D Decoder -12 Volt Power converter x2 (Contains UK USA EU China converters) - Mini USB cable to USB + HDMI cables & Quickstart Encoder ...
- Page 3 2. Setting up the ANT-7000E and D ANT-7000 RAPID264 ULTRA LOW LATENCY KVM VIDEO ENCODER & DECODER PAIR ANT-7000 decoder connected to keyboard and mouse locally + RS232 serial data control port ANT-7000 encoder connected to HDMI, USB & RS232 serial data...
- Page 4 The ANT-7000E default IP address is 192.168.0.171 and the ANT-7000D is 192.168.0.172 . Please connect a laptop ( to be used to configure the ANT-7000 units only) to the ethernet switch. Set the laptop Ethernet IP address to be in the same sub-domain e.g 192.168.0.XXX...
- Page 5 I frame and spreads it over the P frames reducing peak network bandwidth. The Intra Count determines over how many P frames is one I frame divided over GOP size is how many P to I frames in GOP mode. Page ! 5 Antrica Quick Start Guide ANT-7000...
- Page 6 The ANT-7000D default IP address is 192.168.0.172 and the ANT-7000E is 192.168.0.171 . Please connect a laptop ( to be used to configure the ANT-7000 units only) to the ethernet switch. Set the laptop Ethernet IP address to be in the same sub-domain e.g 192.168.0.XXX...
- Page 7 Display tells you what display is connected and what resolution the decoder is outputting. If not connected to an Encoder or display this page will be blank. 4.3 Serial Control: Decoder This page sets serial baud rate for both RS232 connections encoder and decoder Page ! 7 Antrica Quick Start Guide ANT-7000...
- Page 8 When Encoder and decoder are streaming correctly and HDMI input and output are connected correctly all 3 LEDs are ON. 5.0 Help and Further Support Please visit www.antrica.com and find the ANT-7000 product page where you can find in the DOWNLOADS section: - application notes...
