PROAIM P-OHCP-01 Assembly Manual

3ft overhead platform for camera & studio lights

3ft Overhead Platform for Camera & Studio Lights

(P-OHCP-01)

A s s e m b l y M a n u a l

What's In The Box

Please inspect the contents of your shipped package to ensure you have received everything that is listed

below.

1 x Cross Bar

2 x Ground Foot

2 x Side bar

2 x Plastic Clips

9 x Foot Thumb Screw &

2 x L Bracket

8 x M5 Short Thumb Screw

4 x Support bar

1 x Camera Mount

No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable copyright

statutes or in writing by the Publisher.

Table of Contents

Need help?

Do you have a question about the P-OHCP-01 and is the answer not in the manual?

Page 1 3ft Overhead Platform for Camera & Studio Lights (P-OHCP-01) A s s e m b l y M a n u a l What’s In The Box Please inspect the contents of your shipped package to ensure you have received everything that is listed below.
Page 2 3ft Overhead Platform Setup  Slide and place the side bar on the ground foot. Lock the assembly using 1/4-20 foot thumbscrew.  Side Bar is properly attached to the ground foot.  Attach the support bar on the side bar using the long M5 Short knob.
Page 3  Adjust the cross bar height by sliding it along the side bar. NOTE: Camera Platform slide on crossbar as per your requirement. NOTE: The Overhead Platform's crossbar is up/ down adjustable & easily mounts through rosette knobs. The Camera Holder with a ¼"-20 screw can be locked into any position on the crossbar.
Page 4 Clamp your backdrop to the brackets using two clips. NOTE: backdrop & other related accessories are not included with the Overhead Camera Platform. YOUR PROAIM 3FT OVERHEAD PLATFORM FOR CAMERA & STUDIO LIGHTS ALL DRESSED UP AND READY TO GO! (SHOWN WITH OPTIONAL ACCESSORIES)
Page 5 Warranty: We offer one year warranty for our products from date of purchase. Within this period of time, we will repair it without charge for labor or parts. Warranty doesn’t cover transportation costs nor does it cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspection and evaluation by us.
