9.5 List z merami

Tip
196200250
196200355
196200450
196200560
196200710
196200900
1502021-01
Sl. 143: List z merami
Mere pol. (mm)
A B
2.340 1.120 - 2.620
3.240 1.200 - 2.700 570
3.830 1.270 - 2.770
4.590 1.350 - 2.840
5.690 1.615 - 3.115
7.380 1.615 - 3.115
Tab. 143: Mere
- 423 -
C D (Ø)
412 250
355
710 450
854 560
1.095 710
1.320 900
