MATRIX

The matrix allows to set the signal routing path between the
four amplifier's input channels and the four amplifier's output
connectors.
Blue boxes at the cross intersection between raws and columns
state an open path between sources (raw) and destinations
(columns).

INPATCH

The input patch tab allows to address the input connections
and the input streamer (media player) to the four amplifier's
input channels.
The signal managed by the media player can be routed to the
amplifiers' input channels via the Media-1 OUT and Media-2 OUT.
Kommander-KA04

Network

This menu section allows the user to monitor and set the
network parameters both wired, wireless and Bluetooth.

WiFi

The WiFi can be configured to connect the unit to a wireless
LAN as a CLIENT or, alternatively, to create an independent local
wireless network behaving as HOT SPOT.
By default the WiFi is set as HOT SPOT allowing any mobile
device to connect to the unit.
By default, the SSID of the HOT SPOT is composed by the word
"K-array-" followed by the serial number of the unit; the default
password is the unit's serial number. The SSID and the password
of the HOT SPOT can be modified manually: the QR Code will
change accordingly.
When set as CLIENT, enter the data of the WiFi LAN in order to
connect the unit to that network.
The power switch allows to toggle on and off the WiFi.

Ethernet

Set the IP addressing static or DHCP.
