Kommander-KA04
USER GUIDE

K-REMUCTRL Remote

K-REMUCTRL is the optional wireless remote dedicated to
control the Kommander-KA04 amplifier unit.
In order to use the K-REMUCTRL with the Kommander-KA04
amplifier:
1. ensure the system software is up to date;
2. pull out the dongle from the K-REMUCTRL remote package;
3. plug the dongle to any free USB port on the amplifier rear
panel;
4. switch on both the amplifier and the K-REMUCTRL remote.
The K-REMUCTRL
rechargeable battery with a switch that can extend the batter
life when powered off.
When the battery discharges to approximately 10% remaining
life, the Status LED begins flashing: connect the remote's
charge port to a standard USB port to recharge the internal
battery; use the provided cable.
Status LED
Blinks when transmitting
Unit wake up
Press for waking up the unit from standby mode
Remote Power Switch
Slide for powering the remote
Play/Pause
Press for playing/pause the song
Mute
Press muting the output signals
By default the K-REMUCTRL remote works on the media player
volume only: in order to modify the behaviour of the remote
controller access the embedded web app.
10
remote includes a high-efficiency
Bluetooth
press for setting the system
in pairing more
Skip forward
press for skipping to the next song
Skip backward
press for skipping to the previous song
Volume up
press for rising the volume
Volume down
press for lowering the volume
Micro-USB
recharging port

Configuring The Remote Settings

Once the K-REMUCTRL's dongle in plugged to the amplifier, the
the logo of the remote will appear in the upper right corner of
the embedded web app interface.
Controlled volume type
Select what part of the system the K-REMUCTRL will control:
either the media player volume, or the DSP intup/output
channels volumes
Access the amplifier embedded web app and click on the
remote settings icon in the top right corner.
Navigate the interface down to the K-Remote section.
The remote can control either the embedded media player
(default setting) or the DSP: use the Controlled volume type
selection field to choose what to control.
When DSP is selected, you can set what channels volumes
between input channels or output channels will be controlled
by the remote.
Remote settings
shortcut
