Data
Installing the Korg MIDI Driver into the
Macintosh
In order to use the Korg MIDI Driver,Apple
MIDI Manager and PatchBay must already be
installed. Use the Apple MIDI Manager and
PatchBay that are included with the MIDI
application that you are using.
They are not included with the AG-002B.
When the K org MIDI Dri ver is used, the "Modem
MIDI Out/Port settings" dialog box allows you to
specify the MIDI channels and types of messages that
will be sent to the C-550. If you do not require this
function, you can simply use the Apple MIDI Dri ver
without using the K org MIDI Dri ver. When using the
Apple MIDI Driver or when using a MIDI application
(sequencer) which does not use the Apple MIDI Dri ver.
1.Copy the Korg MIDI Driver from the disk
included with the AG-002B into the system
folder of the start-up drive.
2.If the system folder contains the Apple MIDI
Driver, either delete it or move it to another
folder. Be careful not to delete or move the
Apple MIDI Manager.
* The Korg MIDI Driver includes the functions of the
Apple MIDI Driver.
3.From the Special menu, choose "Restart."
34
Setting up the Korg MIDI Driver
(Macintosh)
1.Start up PatchBay.
If installation has been performed correctly, the Korg
MIDI Driver icon will appear in the PatchBay window
when PatchBay is started up, as shown below. (The
Modem/Printer port displays may be different,
depending on your setup.)
2.In PatchBay, double-click the Korg MIDI
Driver icon.
A setup dialog box will appear.
Time Port
Connected Port
Modem Port
Printer Port
3.Check Port Enabled for the port to which
the C-550 if is connected, and select [1 MHz]
as the Interface Type.
(Since the C-550 if does not contain a Korg PC IF,
do not select [Korg PC IF].)
4.Click the [Out Port Setting] button.
The following dialog box will appear. Here you can
select the MIDI channels/messages that will be
output to each port. Only the channels/messages
which are checked will be output.
MIDI In Port MIDI Out Port
