Summary of Contents for Speco O4VD2
- Page 1 Quick Start Guide O4VD2...
- Page 2 This owner's manual is designed to be a reference tool for your system. Please read this manual carefully before operating the unit and retain it for future reference. Should you require any technical assistance, contact Speco Technologies Tech Support at 1-800-645-5516 Important Safeguards and Warning 1.
- Page 3 Technologies reserves the right to modify these without notice and without incurring any obligation. Speco Technologies is not liable for any loss caused by improper operation. Note: Before installation, check the package and make sure that all components are included.
- Page 4 Camera Quick start guide Plastic screw anchors Screws (PA 4 ×25mm) Rubber plug Screwdriver Drill template Overview Overview Ethernet connector Audio input connector Power connector Microphone Micro SD Card Slot Reset...
-
Page 5: Connecting Network Cable
External microphone DC12V * 1 It is recommended to install the water-proof connector for outdoor installations. * 2 DC 12V power supply is not required if a PoE switch or injector is used to power the camera. ► Connecting Network Cable ①... -
Page 6: Installation
Installation * Before you start, please make sure that the wall or ceiling is strong enough to withstand three times the weight of the camera. ① Attach the drill template to the place where you want to fix the camera and then drill the screw holes and the cable hole on the wall according to the drill template. - Page 7 ③ Loosen the screws to open the lower dome. ④ Route and connect the cables. ⑤ Mount the rubber plug to the gap of the mounting base and then s ecure the camera to the wall with screws provided as shown below. Lower Dome Rubber Plug ⑥...
- Page 8 ⑦ Install the lower dome back to the camera and fasten it with the screws. Then put the trim ring onto the lower dome. Finally, remove the protection film softly. Web Operation and Login IP Scanner can search for the device on the local network. ●...
- Page 9 5C:F2:07:24:58:9A O4VD2 ③ In the device list, you can view the IP address, model number, and MAC address of each device. Select the applicable device and double click to open up the web viewer. You can also manually enter the IP address in the address bar of the web browser.
