- Page 1 Quick Start Guide O4VD1...
- Page 2 This owner's manual is designed to be a reference tool for your system. Please read this manual carefully before operating the unit and retain it for future reference. Should you require any technical assistance, contact Speco Technologies Tech Support at 1-800-645-5516 Important Safeguards and Warning 1.
- Page 3 Technologies reserves the right to modify these without notice and without incurring any obligation. Speco Technologies is not liable for any loss caused by improper operation. Note: Before installation, check the package and make sure that all components are included.
- Page 4 4 tapping screws Camera Quick start guide Drill template ×4 Plastic plug Rubber plug Screwdriver Junction box Overview Overview Ethernet connector Power connector Micro SD Card Slot Reset...
-
Page 5: Connecting Network Cable
DC12V * 1 It is recommended to install the security cap for outdoor installations. * 2 DC 12V power supply is not required if a PoE switch or injector is used to power the camera. ► Connecting Network Cable ① Loosen the nut from the main element. ②... -
Page 6: Installation
Installation * Before you start, please make sure that the wall or ceiling is strong enough to withstand three times the weight of the camera. ① Install junction box onto the wall by using the screws provided. ② Loosen the screws to open the lower dome. - Page 7 ③ Connect the cables, mount the rubber plug to the gap of the mounting base and fasten the camera onto the junction box. ④ Three-axis Adjustment-Before adjustment, preview the image of the camera on a monitor and then adjust the camera according to the figure below to get an optimum angle.
- Page 8 ⑤ Install the lower dome back to the camera and fix it with the screws. Web Operation and Login IP Scanner can search for the device on the local network. ● Operation ① Make sure that the camera and the PC are connected to the same local network.
- Page 9 O4VD1 5C:F2:07:24:58:9A ③ In the device list, you can view the IP address, model number, and MAC address of each device. Select the applicable device and double click to open up the web viewer. You can also manually enter the IP address in the address bar of the web browser.
