Omcan WC-CN-0181-DB Instruction Manual page 20

parts breakdown
Model WC-Cn-0040-Db
Item No. Description
AM687 Handle-Black for 48260
Door Assemble-Full Glass Door for
AM688
48260
79712 Shaft Sleeve for 48260
AM689 Door Gasket (Full Glass Door) for 48260
79718 Upper Wood Shelf for 48260
79719 Sliding Trace-Left for 48260
AM670 Sliding Trace-Right for 48260
79674 Control Box for 48260
79675 Display PCB for 48260
79676 Electric Box Support Left for 48260
Right Support Frame of Upper Electric
68729
Box for 48260
Upper Zone LED Light Strip-Blue for
79725
48260
Lower Zone LED Light Strip-Blue for
AM671
48260
79703 Sealing (Froming) for 48260
79728 Fan-1 for 48260
79729 Back Ventilation Board for 48260
48260
Position Item No. Description
1 79730 Up-Sensor for 48260
2 79731 Evaporator for 48260
3 79732 Sealing PVC for 48260
4 AM672 Upper Hinger for 48260
5 79734 Casing for 48260
6 79735 Compressor for 48260
6 AM673 Water Tray for 48260
8 79737 Compressor Support Plate for 48260
9 79692 Hidden Line Box for 48260
10 AM674 8025 Fan-2 for 48260
10 79694 Power Supply Cord for 48260
12 79689 Electric Board for 48260
12 79742 Condenser for 48260
14 79743 Bottom Reinforcing Bar for 48260
15 AM675 Foot for 48260
16 79745 Down Hinger+Front Foot for 48260
Position Item No.
17 79711
18 79698
19 AM690
20 79749
21 79701
22 79700
23 79752
24 AM666
25 79754
26 79755
27 AM685
28 79708
29 79759
30 79760
31 AM676
32 AM677
20
Description Position
Watershed Plate for 48260 33
Heating Wire for 48260 34
Front Grill - Black for 48260 35
Down Sensor for 48260 36
8025 Fan for 48260 37
Sensor Cap for 48260 38
Top Ventilation Board for 48260 39
8025 Fan for 48260 40
Up Cover (Mid.Board) for 48260 41
Bottom Cover (Mid.Board) for 48260 42
Control Panel Sticker-Black for 48260 43
Fixation Electrical Box (Down) for 48260 45
Bottom Wood Shelf for 48260 46
Carton for 48260 47
Upper Zone LED Light Strip-White for
48
48260
Lower Zone LED Light Strip-White for
49
48260
