Omcan WC-CN-0181-DB Instruction Manual page 15

Model WC-Cn-0181-Db
Item No. Description
AM683 Handle Black for 48258
AM684 Door Assemble Full Glass Door for 48258
79671 Upper Wood Shelf for 48258
79672 Sliding Trace Left for 48258
AM667 Sliding Trace Right for 48258
79676 Electric Box Support Left for 48258
79674 Control Box for 48258
AM665 Electric Box Support Right for 48258
79675 Display PCB for 48258
68795 LED Light Strip Blue for 48258
68797 Sensor Cap Foam for 48258
79681 Fan-1 for 48258
79682 Up-Sensor for 48258
79683 PVC Sink for 48258
Motor General Assembly Drawing for
68798
48258
79684 Evaporator for 48258
79689 Electric Board for 48258
79685 Top Cover for 48258
79686 Upper Hinger for 48258
48258
Position Item No. Description
1 79687 Hinge Cover for 48258
2 79688 Casing for 48258
3 68799 Condenser Strip for 48258
4 79690 Condenser for 48258
4 79691 Water Tray for 48258
5 79692 Hidden Line Box for 48258
6 79693 Compressor for 48258
7 79694 Power Supply Cord for 48258
8 79695 Compressor Support Plate for 48258
9, 10 79696 Front Foot for 48258
11 79697 Down Hinger+Foot for 48258
12 68800 Lock Bracket+Plastic Cushion for 48258
13 79700 Sensor Cap for 48258
14 79698 Heating Wire for 48258
15 79699 Down Sensor for 48258
16 79711 Watershed Plate for 48258
17 79701 8025 Fan for 48258
18 68802 Back Ventilation Board for 48258
19 79703 Sealing (Froming) for 48258
parts breakdown
Position Item No.
20 79704
21 79705
22 79706
23 AM666
24 79707
25 79677
26 AM685
27 79708
28 79709
29 79670
30, 31 79712
32, 33 79713
34 64165
35 68726
36 69707
37 68796
38 AM686
39
40
15
Description Position
Top Ventilation Board for 48258 41
Fixed Plate for 48258 42
Up Cover (Mid. Board) for 48258 43
8025 Fan for 48258 44
Bottom Cover for 48258 45
Control Box PVC for 48258 46
Control Panel Sticker-Black for 48258 47
Fixation Electrical Box (Down) for 48258 48
Bottom Wood Shelf for 48258 49
Door Gasket for 48258 50
Shaft Sleeve for 48258 51
Carton for 48258 52
Slanted Shelf for 48258 53
Starting Compoents for the Compressor
54
LG MA53LBCG for 48258
Key for 48258 55
LED Light Strip - White for 48258 56, 57
Door Limit - Full Glass Door for 48258 58
