Omcan WC-CN-0181-DB Instruction Manual page 18

parts breakdown
Model WC-Cn-0192-sb
Item No. Description
AM683 Handle-Black for 48259
Door Assemble-Full Glass Door for
AM684
48259
79712 Shaft Sleeve for 48259
79670 Door Gasket for 48259
79674 Electric Box for 48259
79675 Display PCB for 48259
79676 Electric Box Support Left for 48259
Right Support Frame of Upper Electric
68729
Box for 48259
79708 Fixation Electrical Box (Down) for 48259
79689 Electric Board for 48259
79704 Top Ventilation Board for 48259
79671 Upper Wood Shelf for 48259
79672 Sliding Trace-Left for 48259
AM667 Sliding Trace-Right for 48259
Model WC-Cn-0192-s
Item No. Description
79668 Handle Stainless Steel for 45259
Door Assemble Stainless Steel Door
79669
for 45259
79712 Shaft Sleeve for 45259
79670 Door Gasket for 45259
79674 Electric Box for 45259
79675 Display PCB for 45259
79676 Electric Box Support Left for 45259
Right Support Frame of Upper Electric
68729
Box for 45259
79708 Fixation Electrical Box (Down) for 45259
79689 Electric Board for 45259
79704 Top Ventilation Board for 45259
79671 Upper Wood Shelf for 45259
79672 Sliding Trace Left for 45259
AM667 Sliding Trace Right for 45259
48259
Position Item No. Description
1 68732 Fan Cover for 48259
2 79700 Sensor Cap for 48259
3 79682 Sensor for 48259
4 79702 Back Ventilation Board for 48259
7 AM668 12025 Fan for 48259
8 68733 Back Ventilation Board Holder for 48259
9 79687 Hinge Cover for 48259
10 79686 Upper Hinge for 48259
11 79690 Condenser for 48259
12 68735 Exhaust Pipe for 48259
15 79691 Water Tray for 48259
17 68736 Dry Filter for 48259
18 79694 Power Supply Cord for 48259
18 79695 Compressor Support Plate for 48259
45259
Position Item No. Description
1 68732 Fan Cover for 45259
2 79700 Sensor Cap for 45259
3 79682 Sensor for 45259
4 79702 Back Ventilation Board for 45259
7 AM668 12025 Fan for 45259
8 68733 Back Ventilation Board Holder for 45259
9 79687 Hinge Cover for 45259
10 79686 Upper Hinge for 45259
11 79690 Condenser for 45259
12 68735 Exhaust Pipe for 45259
15 79691 Water Tray for 45259
17 68736 Dry Filter for 45259
18 79694 Power Supply Cord for 45259
18 79695 Compressor Support Plate for 45259
Position Item No.
19 79696
20 79697
21 79693
22 68800
23 79711
24 68738
26 AM669
27 79709
28 79679
29 AM686
30 AM685
31 69707
32
33
Position Item No.
19 79696
20 79697
21 79693
22 68800
23 79711
24 68738
26 AM669
27 79709
28 79679
29 68739
30 79710
31 69707
32
33
18
Description Position
Front Foot for 48259 34
Down Hinger+Front Foot for 48259 36
Compressor for 48259 37
Lock Bracket+Plastic Cushion for 48259 38
Watershed Plate for 48259 39
Back Ventilation Board Holder for 48259 40
Evaporator for 48259 42
Bottom Wood Shelf for 48259 43
LED Light for 48259 44
Door Limit - Full Glass Door for 48259 45
Control Panel Sticker-Black for 48259 46
Key for 48259 54
Description Position
Front Foot for 45259 34
Down Hinger+Front Foot for 45259 36
Compressor for 45259 37
Lock Bracket+Plastic Cushion for 45259 38
Watershed Plate for 45259 39
Back Ventilation Board Holder for 45259 40
Evaporator for 45259 42
Bottom Wood Shelf for 45259 43
LED Light for 45259 44
Stainless Steel Door Limit Block for
45
45259
Control Panel Sticker Silver for 45259 46
Key for 45259 54
