Bread Slicers
Models SB-CN-0025, 0013, 0019, 0016, 0011
Items 44246, 44247, 44248, 44249, 44250
Instruction Manual
Revised - 01/18/2023
Toll Free: 1-800-465-0234
Fax: 905-607-0234
Email: service@omcan.com
www.omcan.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SB-CN-0025 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Omcan SB-CN-0025

  • Page 1 Bread Slicers Models SB-CN-0025, 0013, 0019, 0016, 0011 Items 44246, 44247, 44248, 44249, 44250 Instruction Manual Revised - 01/18/2023 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...
  • Page 2: Table Of Contents

    Table of Contents Model SB-CN-0025 / Model SB-CN-0013 / Model SB-CN-0019 Model SB-CN-0016 / Model SB-CN-0011 Section Page General Information --------------------------------------------------------------------------- 3 - 4 Safety and Warranty --------------------------------------------------------------------------- 4 - 5 Technical Specifications -------------------------------------------------------------------------- 6 Installation -------------------------------------------------------------------------------------------- 6 Operation --------------------------------------------------------------------------------------------- 6...
  • Page 3: General Information

    If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents.
  • Page 4: Safety And Warranty

    Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia.
  • Page 5 1 YEAR PARTS AND LABOR WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized service technician to repair the equipment locally. Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not improper use.
  • Page 6: Technical Specifications

    Technical Specifications Model SB-CN-0025 SB-CN-0013 SB-CN-0019 SB-CN-0016 SB-CN-0011 Power 0.25 HP / 0.18 kW Size 1” / 25mm 1/2” / 13mm 3/4” / 19mm 5/8” / 16mm 7/16” / 11mm Electrical 110-120V / 60Hz / 1 Weight 176 lbs. / 79.8 kgs.
  • Page 7: Troubleshooting

    Maintenance CHANGING BLADES TO REMOVE THE BLADES 1. Remove the top cover and the guide. 2. Remove the exit chute. 3. Remove the support angle on each side of the chute (10mm key). 4. Unscrew bolt. 5. Unscrew the bottom bolt on the blade frame. 6.
  • Page 8: Parts Breakdown

    Parts Breakdown Model SB-CN-0025 44246 Model SB-CN-0013 44247 Model SB-CN-0019 44248 Model SB-CN-0016 44249 Model SB-CN-0011 44250...
  • Page 9 Parts Breakdown Model SB-CN-0025 44246 Item No. Description Position Item No. Description Position Item No. Description Position 63586 Right Wall for 44246 63610 Lower Fixed Plate (Right) for 44246 63634 Screw M8x16 for 44246 63587 Nut M10 for 44246 63611...
  • Page 10 Parts Breakdown Model SB-CN-0013 44247 Item No. Description Position Item No. Description Position Item No. Description Position 63586 Right Wall for 44247 63610 Lower Fixed Plate (Right) for 44247 63634 Screw M8x16 for 44247 63587 Nut M10 for 44247 63611 Frame Fixed Rod for 44247 63635 Washer Ø8 for 44247...
  • Page 11 Parts Breakdown Model SB-CN-0019 44248 Item No. Description Position Item No. Description Position Item No. Description Position 63586 Right Wall for 44248 63610 Lower Fixed Plate (Right) for 44248 63634 Screw M8x16 for 44248 63587 Nut M10 for 44248 63611 Frame Fixed Rod for 44248 63635 Washer Ø8 for 44248...
  • Page 12 Parts Breakdown Model SB-CN-0016 44249 Item No. Description Position Item No. Description Position Item No. Description Position 63586 Right Wall for 44249 63610 Lower Fixed Plate (Right) for 44249 63634 Screw M8x16 for 44249 63587 Nut M10 for 44249 63611 Frame Fixed Rod for 44249 63635 Washer Ø8 for 44249...
  • Page 13 Parts Breakdown Model SB-CN-0011 44250 Item No. Description Position Item No. Description Position Item No. Description Position 63586 Right Wall for 44250 63610 Lower Fixed Plate (Right) for 44250 63634 Screw M8x16 for 44250 63587 Nut M10 for 44250 63611 Frame Fixed Rod for 44250 63635 Washer Ø8 for 44250...
  • Page 14: Electrical Schematics

    Electrical Schematics Model SB-CN-0025 44246 Model SB-CN-0013 44247 Model SB-CN-0019 44248 Model SB-CN-0016 44249 Model SB-CN-0011 44250...
  • Page 15: Warranty Registration

    Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté...
  • Page 16 Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers.
