6 Hardware References

When the controlCARD is used in a high-voltage setup, it is the user's responsibility to confirm that
the voltages and isolation requirements are identified and understood prior to energizing the board
or simulation. When energized, the controlCARD or components connected to the controlCARD
can not be touched. Furthermore, the capacitor C7:A can be removed to minimize the possibility of
leakage current flowing across the isolation barrier of the controlCARD.
SPRUJ15B – NOVEMBER 2021 – REVISED OCTOBER 2022
Submit Document Feedback
WARNING

Figure 6-1. Key Components on the controlCARD - Front
