Flat PCAP Panel PC

Intel

Document Version 1.2

Document Part No.

91521110107X

IP65 Stainless

Core™ Whiskey Lake i5-8265U 1.6GHz

User Manual

15"/ 17"/ 19"/ 21.5"/ 23.8"

Model No. R15IW3S-SPC3

R17IW3S-SPA1

R19IW3S-SPM1

W22IW3S-SPA3

W24IW3S-SPA2

Table of Contents

Need help?

Do you have a question about the R15IW3S-SPC3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Winmate R15IW3S-SPC3

Page 1 IP65 Stainless Flat PCAP Panel PC Core™ Whiskey Lake i5-8265U 1.6GHz ® Intel 15”/ 17”/ 19”/ 21.5”/ 23.8” Model No. R15IW3S-SPC3 R17IW3S-SPA1 R19IW3S-SPM1 W22IW3S-SPA3 W24IW3S-SPA2 User Manual Document Version 1.2 Document Part No. 91521110107X...
Page 3: Table Of Contents
IP65 Flat Stainless PCAP Panel PC User Manual Contents Preface ............................3 About This User Manual ........................ 8 Chapter 1: Introduction ......................... 9 1.1 Product Features ......................9 1.2 Package Content ......................10 1.3 Connector Placement ....................11 1.4 Physical Buttons and LED Indicators ................12 1.5 Schematics and Dimensions ..................
Page 4 IP65 Flat Stainless PCAP Panel PC User Manual 4.2.3 Boot ........................48 4.2.4 Security ......................52 4.2.5 Power ........................53 4.2.6 Exit ........................54 4.3 Using Recovery Wizard to Restore Computer ............... 55 Chapter 5: Driver Installation ...................... 57 5.1 Installing Chipset Driver ....................57 5.2 Installing Graphics Driver ....................
Page 5: Preface
Brand and product names are trademarks or registered trademarks of their respective owners. Disclaimer Winmate Inc. reserve the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance.
Page 6 Preface Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory. NOTE: A note is used to emphasize helpful information IMPORTANT:...
Page 7 IP65 Flat Stainless PCAP Panel PC User Manual Safety Information WARNING! / AVERTISSEMENT! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis.
Page 8 Preface the equipment. • All cautions and warnings on the equipment should be noted. *Let service personnel to check the equipment in case any of the following problems appear: o The power cord or plug is damaged. o Liquid has penetrated into the equipment. o The equipment has been exposed to moisture.
Page 9 IP65 Flat Stainless PCAP Panel PC User Manual Federal Communications Commission Radio Frequency Interface Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference. ⚫ This device must accept any interference received including interference that ⚫...
Page 10: About This User Manual
IP65 Flat Stainless PCAP Panel PC User Manual About This User Manual This User Manual provides information about using the Winmate® IP65 Flat Stainless PCAP Panel PC with Intel® Core™ Whiskey Lake i5-8265U 1.6GHz processor. This User Manual applies to the IP65 Flat Stainless PCAP Panel PC –R15IW3S-SPC3, R17IW3S-SPA1, R19IW3S-SPM1,...
Page 11: Chapter 1: Introduction
PCAP multi-touch screen supports glove mode and provides even more convenience for the operator. Winmate® IP65 Flat Stainless PCAP Panel PC goes beyond that of the standard industrial panel computers with elegant, edge-to-edge design, rugged construction, powerful performance, and flexible mounting options.
Page 12: Package Content
IP65 Flat Stainless PCAP Panel PC User Manual 1.2 Package Content Carefully remove the box and unpack your Panel PC. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. Standard factory shipment list Quick Start Guide Panel PC...
Page 13: Connector Placement
Chapter 1: Introduction 1.3 Connector Placement IP65 Flat Stainless PCAP Panel PC has IP65 type connectors with protection cap. For cable specifications refer to the 2.2 Connector Pin Assignments of this user manual.
Page 14: Physical Buttons And Led Indicators
IP65 Flat Stainless PCAP Panel PC User Manual 1.4 Physical Buttons and LED Indicators Physical buttons and LED indicators located on the rear side of the Panel PC. Physical Buttons Icon Button Description Reset Press to reset the system Power On/ Press to power on or power off the device LED Indicators LED Type...
Page 15: Schematics And Dimensions
Chapter 1: Introduction 1.5 Schematics and Dimensions This section contains mechanical drawing of the panel PC. Notice that this is a simplified drawing and some components are not marked in detail. 1.5.1 Dimensions 15" Unit: mm 1.5.2 Dimensions 17” Unit: mm...
Page 16: Dimensions 19
IP65 Flat Stainless PCAP Panel PC User Manual 1.5.3 Dimensions 19” Unit: mm 1.5.4 Dimensions 21.5” Unit: mm...
Page 17: Dimensions 23.8
Chapter 1: Introduction 1.5.5 Dimensions 23.8” Unit: mm...
Page 18: Chapter 2: Getting Started
IP65 Flat Stainless PCAP Panel PC User Manual Chapter 2: Getting Started This chapter provides information on how to connect the panel PC to the source of power, connector pinouts and the guideline to turn on/off the Panel PC. 2.1 Powering On 2.1.1 AC Adapter Components AC Adapter supplied with the power cord.
Page 19: Power Considerations
Chapter 2: Getting Started ALTERNATING CURRENT / MISE À LE TERRE! This product must be grounded. Use only a grounded AC outlet. Install the additional PE ground wire if the local installation regulations require it. *If you do not use a grounded outlet while using the device, you may notice an electrical tingling sensation when the palms of your hands touch the device.
Page 20: Connecting The Power
IP65 Flat Stainless PCAP Panel PC User Manual 2.1.4 Connecting the Power Cable Mounting Steps: Connect the AC adapter to the DC-in jack connector located on the back side of the Panel PC. Connect the power cord to AC adapter. Plug the power cord to the AC outlet and the device will turn on automatically.
Page 21: Connector Pin Assignments
Chapter 2: Getting Started 2.2 Connector Pin Assignments This Panel PC is equipped with four connectors which are IP65 level and fool-proofing design. Use only the cables that are included in the package. The pin assignments of the cables are as follows. 2.2.1 Power Cable The Flat Stainless PCAP Panel PC has IP65 connector.
Page 22: Ethernet Cable
IP65 Flat Stainless PCAP Panel PC User Manual 2.2.3 Ethernet Cable The Flat Stainless PCAP Panel PC has IP65 Ethernet connector. Use Ethernet cable to connect the Panel PC to the Internet. 2.2.4 USB 2.0 Cable Flat Stainless PCAP Panel PC has one Full IP65 USB2.0 connector. Use USB2.0 cable to connect external devices such as mouse or keyboard to the Panel PC.
Page 23: Turning On And Off
Chapter 2: Getting Started 2.3 Turning On and Off The unit is configured to Power ON when is connected to the power source (refer to 2.1 Powering section of this user manual for more details on how to power on the HMI device). You can Turn OFF the Panel PC with the Windows power settings.
Page 24: Chapter 3: Operating The Device
IP65 Flat Stainless PCAP Panel PC User Manual Chapter 3: Operating the Device In this chapter you will find instructions on how to operate the Panel PC with Hot Tab. 3.1 Operating System Flat Stainless PCAP Panel PC support several versions of Windows OS: Windows 10 IoT Enterprise, Windows Embedded 8.1 Industry Pro, Windows Embedded 8 Standard, Windows 7 Pro for Embedded Systems, and Windows Embedded Standard 7 –...
Page 25 If the OS is not installed, please download the application on our website for switching the touch modes. If you cannot find it, please download it from Winmate Download Center or contact Winmate sales representative.
Page 26 IP65 Flat Stainless PCAP Panel PC User Manual Follow the instructions below to install the TouchModeSelect Utility. 1. Download, install and execute TouchModeSelect_1.2.3 setup wizard. 2. Click Next to continue. 3. Select the installation folder, and click Next to continue. 4.
Page 27 Chapter 3: Operating the Device 5. When installation is complete, click Finish button to exit the Setup Wizard.
Page 28: How To Enable Watchdog
IP65 Flat Stainless PCAP Panel PC User Manual 3.3 How to Enable Watchdog To enable Watchdog, you need to download Winmate Watchdog utility. Find more information on Watchdog in “Watchdog Guide” that you can download from Winmate Download Center or File Share.
Page 29: Chapter 4: Insyde H20 Bios Setup
Chapter 4: Insyde H20 BIOS Setup Chapter 4: Insyde H20 BIOS Setup BIOS Setup Utility is a program for configuration basic Input / Output system settings of the computer for optimum use. This chapter provides information on how to use BIOS setup, its functions and menu.
Page 30: Bios Functions
IP65 Flat Stainless PCAP Panel PC User Manual 4.2 BIOS Functions 4.2.1 Main Menu The Main menu displays the basic information about yoursystem including BIOS version, processor RC version, system language, time, and date. When you enter BIOS setup, the first menu that appears on the screen is the main menu.It contains the system information including BIOS version, processor RC version, system language, time, and date.
Page 31: Advanced
Chapter 4: Insyde H20 BIOS Setup 4.2.2 Advanced Select the Advanced Tab from the setup menu to enter the advanced BIOS setup screen. You can select any of the items on the left frame of the screen to go to the sub menu for the item, such as CPU Configuration.
Page 32 IP65 Flat Stainless PCAP Panel PC User Manual 4.2.2.1 CPU Configuration...
Page 33 Chapter 4: Insyde H20 BIOS Setup BIOS Setting Description Setting Option Effect Intel (VMX) Enable/Disable When enabled, a Enable disable Virtualization Intel Virtualization VMM can utilize the Technology Technology. additional hardware capabilities provided Vanderpool Technology. Active Processor Number of core to AII / 1 / 2/ 3 Select number of Cores...
Page 34 IP65 Flat Stainless PCAP Panel PC User Manual 4.2.2.2 F81886A Configuration...
Page 35 Chapter 4: Insyde H20 BIOS Setup 4.2.2.3 GPIO Configuration...
Page 36 IP65 Flat Stainless PCAP Panel PC User Manual...
Page 37 Chapter 4: Insyde H20 BIOS Setup 4.2.2.4 Hardware Monitor...
Page 38 IP65 Flat Stainless PCAP Panel PC User Manual 4.2.2.5 PCH-IO Configuration BIOS Setting Description Setting Option Effect Express PCI Express clock gating Enter Opens sub-menu Configuration enable/disable for each root port. SATA Enable/ Disable SATA Enter Opens sub-menu device Configuratuion Selectively enable/ Enter...
Page 39 Chapter 4: Insyde H20 BIOS Setup 4.2.2.6 PCI Express Configuration...
Page 40 IP65 Flat Stainless PCAP Panel PC User Manual...
Page 41 Chapter 4: Insyde H20 BIOS Setup 4.2.2.7 SATA and RST Configuration...
Page 42 IP65 Flat Stainless PCAP Panel PC User Manual 4.2.2.8 USB Configuration...
Page 43 Chapter 4: Insyde H20 BIOS Setup 4.2.2.9 ME Firmware Configuration...
Page 44 IP65 Flat Stainless PCAP Panel PC User Manual 4.2.2.10 Power & Performance BIOS Setting Description Setting Option Effect CPU – Power Configure CPU – Enter Opens sub-menu Management Power Management Control parameters...
Page 45 Chapter 4: Insyde H20 BIOS Setup...
Page 46 IP65 Flat Stainless PCAP Panel PC User Manual BIOS Setting Description Setting Option Effect Boot Configure Boot -Max non-turbo Select the performance Performance Performance Mode performance state that the BIOS will set Mode parameters -Max battery starting from reset vector -Turbo Performance Intel...
Page 47 Chapter 4: Insyde H20 BIOS Setup 4.2.2.11 System Agent (SA) Configuration BIOS Setting Description Setting Option Effect Graphics Configure Enter Opens sub-menu Configuration Graphics Configuration parameters Vt-d Intel® Enabled Vt-d capability Virtualization Disabled Technology Directed I/O...
Page 48 IP65 Flat Stainless PCAP Panel PC User Manual 4.2.2.11.1 Graphics Configuration BIOS Setting Description Setting Option Effect Internal Graphics Internal Auto Keep IGFX enabled based Graphics Enabled on the setup options settings Disabled Aperture Size Select 128MB Select the aperture size aperture size 256MB Note: Above 4MB MMIO...
Page 49 Chapter 4: Insyde H20 BIOS Setup 4.2.2.11.2 Vt-d BIOS Setting Description Setting Option Effect Vt-d Intel® Enabled Vt-d capability Virtualization Disabled Technology Directed I/O...
Page 50: Boot
IP65 Flat Stainless PCAP Panel PC User Manual 4.2.3 Boot BIOS Setting Description Setting Option Effect UEFI Boot Type Select boot type to Dual type, Boot Type Boot Type Legacy type or UEFI type configuration Enabled Allows InsydeH20 skip Quick Boot Quick Boot Disabled...
Page 51 Chapter 4: Insyde H20 BIOS Setup...
Page 52 IP65 Flat Stainless PCAP Panel PC User Manual 4.2.3.1 Boot Type Order BIOS Setting Description Setting Option Effect Enter Opens Sub-menu Hard Disk Type Hard Disk Type configuration Enter Opens Sub-menu Others Other configuration...
Page 53 Chapter 4: Insyde H20 BIOS Setup 4.2.3.1.1 Others...
Page 54: Security
IP65 Flat Stainless PCAP Panel PC User Manual 4.2.4 Security BIOS Setting Description Setting Option Effect TrEE Protovol TrEE Protocol Choose TrEE Version: 1.0 or 1.1 Version Protocol Version Available When hidden don’t TPM Availability Availability Hidden exposes TPM to 0 configuration Select one of the TPM Operation...
Page 55: Power
Chapter 4: Insyde H20 BIOS Setup 4.2.5 Power BIOS Setting Description Setting Option Effect Disabled Enable/ Disable ACPI S3 ACPI Enabled ACPI S1/S3 Sleep configuration state Disabled Auto Wake on S5 Auto Wake on S5 Auto Wake on S5, By Every Day configuration by Day or Month By Every Month...
Page 56: Exit
IP65 Flat Stainless PCAP Panel PC User Manual 4.2.6 Exit...
Page 57: Using Recovery Wizard To Restore Computer
Chapter 4: Insyde H20 BIOS Setup 4.3 Using Recovery Wizard to Restore Computer The Panel PC has a dedicate recovery partition stored on the hard drive of the PC to enable quick one-key recovery process. This partition occupies about 11GB of the storage space, and comes built-in to the PC.
Page 58 IP65 Flat Stainless PCAP Panel PC User Manual Wait the recovery process to complete. During the recovery process, a command prompt will show up to indicate the percent of recovery process complete. The system will restart automatically after recovery completed.
Page 59: Chapter 5: Driver Installation
Chapter 5: Driver Installation Chapter 5: Driver Installation This chapter provides guideline to driver installations. 5.1 Installing Chipset Driver Step 1 Insert the CD that comes with the motherboard. Open the file document “Chipset Driver” and click “infinst_auto.exe” to install driver. Step 2 Click Next to continue.
Page 60 IP65 Flat Stainless PCAP Panel PC User Manual Step 4 Click Next to install the driver. Step 5 Software setup progress window will appear, click Next to continue. Step 6 Click “Yes, I want to restart this computer now” to finish the installation.
Page 61: Installing Graphics Driver
Chapter 5: Driver Installation 5.2 Installing Graphics Driver Step 1 Insert the CD that comes with the motherboard. Open the file document “Graphics Driver” and click Setup to execute the setup. Step 2 Setup Welcome Window will appear, click Next to continue the process. Step 3 Carefully read the license terms and click Yes to agree.
Page 62: Installing Intel Sideband Fabric Device (Intel Mbi) Driver (Windows 8)
IP65 Flat Stainless PCAP Panel PC User Manual 5.3 Installing Intel Sideband Fabric Device (Intel MBI) Driver (Windows 8) Step 1 Insert the CD that comes with the motherboard. Open the file document “MBI” and click “Setup.exe” to install the driver. Step 2 Welcome to the setup program window will appear, click Next to start the installation.
Page 63: Installing Intel Trusted Engine Interface (Intel Txe) Driver
Chapter 5: Driver Installation 5.4 Installing Intel Trusted Engine Interface (Intel TXE) Driver Step 1 Insert the CD that comes with the motherboard. Open the file document “TXE” and click “Setup TXE.exe” to install the driver. Step 2 Welcome to the setup program window will appear, click Next to start the installation. Step 3 Carefully read the license terms and click Yes to agree.
Page 64: Installing Intel Network Connections
IP65 Flat Stainless PCAP Panel PC User Manual 5.5 Installing Intel Network Connections User must confirm the type of operating system is being used before installing Intel Network Connections. Follow the steps below to complete the installation. Step 1 Click “PROWin64.exe” Step 2 Click Yes to start the installation.
Page 65: Installing Audio Driver
Chapter 5: Driver Installation 5.6 Installing Audio Driver The ALC886 series are high-performance 7.1+2 channel high definition audio codecs that provide ten DAC channels for simultaneous support of 7.1 sound playback, plus 2 channels of independent stereo sound output (multiple streaming) through the front panel stereo outputs. The series integrates two stereo ADCs that can support a stereo microphone, and feature Acoustic Echo Cancellation (AEC), Beam Forming (BF), and Noise Suppression (NS) technology.
Page 66: Chapter 6: Mounting
IP65 Flat Stainless PCAP Panel PC User Manual Chapter 6: Mounting This chapter provides mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages. WARNING! / AVERTISSEMENT! Follow mounting instructions and use recommended mounting hardware to avoid the risk of injury.
Page 67: Mounting Guide
Refer to sub-sections below for more details. 6.3.1 VESA Mount Flat Stainless PCAP Panel PC has VESA mount holes on the rear side. Follow instructions below to mount the unit with VESA Mount bracket (not supplied by Winmate). Size VESA Plate...
Page 68: Yoke Mount
Notice that both hooks on bracket should lock the notches on the back cover of the device. 6.3.2 Yoke Mount Yoke Mount solution allows installing the Panel PC with the bracket (not supplied by Winmate). Mounting instruction: 1. Place the Panel PC on the bracket stand, aiming screw holes for each other.
Page 69: Chapter 7: Technical Support
This chapter includes technical support documents and software developing kit (SDK). If any problem occurs fill in problem report form enclosed and immediately contact us. 7.1 Software Developer Support Winmate provides the following SDK and Utilities for the IP65 Flat Stainless PCAP Panel PC Item File Type Description Watchdog SDK Utility Watchdog Utility To find the Drivers and SDK, please refer to the Driver CD that comes in the package or contact us.
Page 70: Problem Report Form
IP65 Flat Stainless PCAP Panel PC User Manual 7.2 Problem Report Form IP65 Flat Stainless PCAP Panel PC Customer name: Company: Tel.: Fax: E-mail: Date: Product Serial Number: ____________________________________________________ Problem Description: Please describe the problem as clearly as possible. Detailed description of the occurred problem will allow us to find the best solution to solve the problem as soon as possible.
Page 71: Appendix A: Product Specifications
Appendix A: Product Specifications Appendix A: Product Specifications Model Name R15IW3S-SPC3 R17IW3S- SPA1 R19IW3S-SPM1 W22IW3S-SPA3 W24IW3S-SPA2 Display 15” 17” 19” 21.5” Size 23.8” Resolution 1024 x 768 1280 x 1024 1280 x 1024 1920 x 1080 1920 x 1080 300 ��/��...
Page 72 IP65 Flat Stainless PCAP Panel PC User Manual Model Name R15IW3S-SPC3 R17IW3S- SPA1 R19IW3S-SPM1 W22IW3S-SPA3 W24IW3S-SPA2 Mechanical Specification Cooling Fanless Fanless Fanless Fanless Fanless System Yoke Mount, Yoke Mount, Yoke Mount, Yoke Mount, Yoke Mount, Mounting VESA Mount VESA Mount...
Page 73: Appendix B: Order Information
Appendix B: Order Information Appendix B: Order Information IP65 Flat Stainless PCAP Panel PC available for ordering in the following configurations. Panel PC SODIMM DDR3L Max 8GB OS Windows 10 IoT Enterprise Windows Embedded 8.1 Industry Pro Windows Embedded 8 Standard Windows Embedded 7 Standard Storage Mini PCIe SSD Touch...
