SIMPLIHOME brooklyn+max WyndenHall AXCHRP-08-BL Manual

Bookcase with storage
Hide thumbs

Advertisement

Quick Links

Download this manual
Harper / Pearson / Thompson
Bookcase with Storage
Model # AXCHRP-08-BL
TM
TM
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the brooklyn+max WyndenHall AXCHRP-08-BL and is the answer not in the manual?

Questions and answers

Related Manuals for SIMPLIHOME brooklyn+max WyndenHall AXCHRP-08-BL

Summary of Contents for SIMPLIHOME brooklyn+max WyndenHall AXCHRP-08-BL

  • Page 1 Harper / Pearson / Thompson Bookcase with Storage Model # AXCHRP-08-BL...
  • Page 2 Great quality is a right. Thank you for shopping with Simpli Home, America's top brand for high-value furniture. It's time to register your product warranty. It's quick and easy. And you'll be happy you did. ü Activate your 1-year warranty ü...
  • Page 3 Review your product and collect rewards! Thank you for your purchase! We hope you enjoy it. We’d love your feedback. Please share a review and get instant rewards! simpli-home.com/product-review Share photos and get your cash back! Send us images or share them on social and qualify for instant rewards.
  • Page 4 For Fastest Customer Service: Open your phone’s camera. Point your phone’s camera at the QR code to scan. Click on the pop up. You’ll be taken to our customer service page. Fill the form with your order information and issue. Submit form.

  • Page 5: Safety Information

    IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. Safety Information CAUTION: Injuries and damage can occur from furniture tip over if product is not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint provided with the product.

  • Page 6: Care And Maintenance

    Care & Maintenance This furniture is designed for indoor use. Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls, and in doing so it swells and shrinks. Making matters worse, it expands and contracts unequally along different grain directions.
  • Page 7 Pre-Assembly Information Model # AXCHRP-08-BL Part Description LEFT SIDE RIGHT SIDE QTY 1 QTY 1 QTY 1 Warning Label BOTTOM BACK PANEL FIXED SHELF QTY 1 QTY 1 QTY 2 CABINET SHELF LEG (L&R Same) DRAWER FRONT QTY 2 QTY 2 QTY 1...
  • Page 8 Pre-Assembly Information Model # AXCHRP-08-BL Part Description LEFT DRAWER SIDE RIGHT DRAWER SIDE DRAWER BACK QTY 1 QTY 1 QTY 1 DRAWER BOTTOM QTY 1...
  • Page 9 Pre-Assembly Information Model # AXCHRP-08-BL Hardware Description ALLEN KEY SCREW ALLEN KEY M6 X 30mm QTY 14 QTY 1 PHILLIPS SCREW ROUND HEAD CAM LOCK PIN M4 X 15mm CAM LOCK SHELF SUPPORT QTY 20 QTY 22 SETS QTY 12 Required - Flathead screwdriver Phillips screwdriver...
  • Page 10 Components - Key Diagram Model # AXCHRP-08-BL...
  • Page 11 Assembly Model # AXCHRP-08-BL Step 1 1. Attach four Cam Lock Pins 5 into pre-drilled holes on back of Drawer Front H . 2. Align Cam Lock Pins with guide holes and attach Drawer Sides IL , IR . 3. Insert two Cam Locks 5 into guide holes on each Drawer Side IL , IR . 4.
  • Page 12 Assembly Model # AXCHRP-08-BL Step 3 1. Align Drawer Back J with Drawer Bottom K and press firmly into slot. 2. Attach Drawer Back J using two Allen Key Screws 1 through guide holes on each Drawer Side IL , IR . 3.
  • Page 13 Assembly Model # AXCHRP-08-BL Step 4 1. Attach six Cam Lock Pins 5 into pre-drilled holes on back of each Side AL , AR . 2. Align Cam Lock Pins with guide holes and attach Fixed Shelves D . 3. Insert six Cam Locks 5 into guide holes on each Fixed Shelf D . 4.
  • Page 14 Assembly Model # AXCHRP-08-BL Step 6 1. Attach Legs G to Bottom C . 2. Use four Allen Key Screws 1 to secure part C and G (two Screws on each Leg) 3. Use eight sets Allen Key Bolts, Lock Washers and Washers 2 to secure part C and G (four sets on each Leg).
  • Page 15 Assembly Model # AXCHRP-08-BL Step 7 1. Attach six Cam Lock Pins 5 into pre-drilled holes underneath of Top B . 2. Align Cam Lock Pins with guide holes and attach Sides AL , AR . 3. Insert three Cam Locks 5 into guide holes on each Side AL , AR . 4.
  • Page 16 Assembly Model # AXCHRP-08-BL Step 8 NOTE: The screwdriver is not included in the hardware pack. Warning Label 1. Attach Back Panel E to back frame of bookcase using twenty Phillips Screws Round Head 4 through guide holes.
  • Page 17 Assembly Model # AXCHRP-08-BL Step 9 shelf support anti - tipping shelf level 1 shelf level 2 shelf level 3 1. Use four Shelf Supports 6 for each Cabinet Shelf F in desired location . 2. Two Shelf Supports 6 may be used on back top of each Cabinet Shelf F as a tipping restraint.
  • Page 18 Assembly Model # AXCHRP-08-BL Step 10 1. Insert six Plastic Caps 7 into holes Cam Locks on Sides AL , AR . 2. Insert assembly drawer into glides on assembly bookcase.
  • Page 19 Furniture Tip Over Restraint Assembly WARNING Serious or fatal crushing injuries can occur from furniture tip-over. If the furniture tip over restraint kit is not in the box, please contact our customer service department in order to obtain another kit before using the furniture. Step 11 NOTE: The screwdriver is not included in the hardware pack.
  • Page 20 Furniture Anti-Tipping Restraint Instructions Attach one of the mounting brackets securely to the back edge of the furniture. Use the shorter screw. Determine where furniture is to be placed and mark location on the wall for mounting bracket screw hole approximately 2 inches below the bracket mounted to the furniture.
