H3C ICG2000 Quick Start Installation

H3C ICG2000 Information Communication Gateway Installation Quick Start-5W104
H3C ICG2000
Installation tools
No installation tools are provided with the device. Prepare them yourself as required.
设备不随机提供安装工具，请用户根据实际安装需求自己准备安装工具。
Flathead Phillips
screwdriver screwdriver
一字螺丝刀 十字螺丝刀
ESD wrist strap Diagonal pliers
防静电腕带 斜口钳
Installation accessories
ICG2000H/2000H-DC mounting ICG2000D/2000D-EI
mounting brackets
brackets
ICG2000D/2000D-EI挂耳
ICG2000H/2000H-DC挂耳
M6 screw(Provided only with ICG2000D/2000D-EI/2000H
the ICG2000D/2000D-EI, user releasable cable tie
supplied for other models) ICG2000D/2000D-EI/2000H
M6机柜螺钉 可拆卸式扎带
(仅ICG2000D/2000D-EI提供，
其它款型用户自备)
ICG2000H-DC terminal block
ICG2000H-DC电源端子
-5W104
Needle-nose pliers Wire-stripper
尖嘴钳 剥线钳
Network cable tester Multimeter
测线仪 万用表
Grounding cable
接地线
ICG2000D/2000D-
EI/2000H power cord
ICG2000D/2000D-
EI/2000H电源线
Rubber feet Console cable
配置电缆
脚垫
When working with the device, always wear an ESD wrist strap, and make sure the strap
makes good skin contact and is reliably grounded.
!
操作者需佩戴防静电腕带，确保防静电腕带与皮肤良好接触，并确认防静电腕带已经良好
接地。
Mounting the device on a workbench
Marker
记号笔
Heat gun
热风枪
M4 screw
M4挂耳螺钉
Mounting the device in a rack
Install cage nuts. 安装浮动螺母
Cage nut
(user supplied)
浮动螺母
(用户自备)
1RU
