CTA PAD-CHKWDC Instruction Manual

Digital Password Combination Security Enclosure
CONTENTS:
A
x1

INSTALLATION:

1. Assembling floorstand base :

J
1A. Align the base plate (B) with the thin VESA profile (A) and screw in
the allen screws (D) with the allen key (J) turning it clockwise until secure-
ly tightened.

3. Attaching enclosure to VESA plate :

C
x4
M5 x 10
x4
A
M5 Nut
3A. Align enclosure (C) holes to VESA plate (A) holes. Turn in Screws
M5 X6 (D) above using provide tool (J) while holding hex nut (E) From
behind with fingers. Shown Above.
Premium Thin Profile Floor Stand w/
PAD-CHKWDC
INSTRUCTION - MANUAL
C D
x4
x1
M5 x 10
H
B
x1
A
B
x4
D
D
J
E
x4
M5 Nut
I
x1
x1

2. Cable routing :

4. Setting up the foam adapters :

4A. Identify the double sided adhesives (G). Peel away the backing
on both sides. Adhesive four of them behind the foam pieces (I) as
illustrated. They are to adhese the foam to the enclosure. Peel away
the back on the next four and place them on top of the foam pieces
as illustrated. These are to attach the foam to the tablets and ensure
security.
888-733-4448
F G
x4
M6
J
x1
M5 Allen Key
2A. Plug one end of the tablet
cord into device, and route the
other end through hole in the
back as shown above.
2B. Cable route from enclosure
to the hole at the top of the body
as shown above.
2C.Insert the cable through
the cutouts at floorstand head
and take it out in the cutout of
the back of the base.
G
I
x1
