Compact Security Gooseneck Floor Stand
CONTENTS:
A
C
x1
INSTRUCTIONS:
1. Attaching Foam Pad to Tablet Holder
Select the appropriate foam pad (N) according to the
thickness of your tablet (or tablet in its case), then
press adhesive side into center of tablet holder.
1mm Foam Pad
N
5mm
Foam Pad
Use this table to determine the
appropriate foam pad to use
with your tablet.
Note: sizes refer to total tablet
size with or without a case.
PAD-SCGS
INSTRUCTION - MANUAL
B
D
E
x2
A
10mm
Foam Pad
Tablet
Foam Pad
Thickness:
Thickness
17-27mm
1mm
0.67-1.06in
/
5mm
0.51-0.91in
/
13-23mm
10mm
0.31-0.71in
/
8-18mm
x1
O
x1
x1
F
x1
x1
2. Installing the Swivel Casters
E
I
H
C
E
G
888-733-4448
G
N
x4
H
I
x4
x4
K
L
x8
x4
2a. Place a
spring washer (I)
over the screw
bolt on each
caster (E).
Screw Nut Cover
Spring
Washer
Metal
Base
2b. Place the
screw bolt from
each wheel (E)
through the
metal base (C),
then place a nut
Wheel
cover (H) over
the top of each.
Screw down
clockwise by
hand, then use
wrench (G) to
tighten further.
x1
J
x4
M
x4
