Industrial Electronic Devices
User Manual
Revision 1.001
English
PROFINET / DeviceNet Slave -
Converter
(Order Code: HD67609-A1)
for Website information:
www.adfweb.com?Product=HD67609
for Price information:
www.adfweb.com?Price=HD67609-A1
Benefits and Main Features:
Very easy to configure
Electrical isolation
Two PROFINET ports
Temperature range: -40°C/85°C (-40°F/185°F)
ADFweb.com Srl – IT31010 – Mareno – Treviso
Other
Products
Axis Solutions Pvt Ltd is the Authorized Distributor of
Axis Solutions Pvt Ltd is the Authorized Distributor of
Axis Solutions Pvt Ltd is the Authorized Distributor of
Axis Solutions Pvt Ltd is the Authorized Distributor of
www.axisindia.in | info@axisindia.in
www.axisindia.in | info@axisindia.in
www.axisindia.in | info@axisindia.in
www.axisindia.in | info@axisindia.in
User Manual PROFINET / DeviceNet Slave
Document code: MN67609_ENG
For others PROFINET products see also the following link:
Converter PROFINET to
www.adfweb.com?Product=HD67606
www.adfweb.com?Product=HD67608
www.adfweb.com?Product=HD67610
www.adfweb.com?Product=HD67600
www.adfweb.com?Product=HD67601
www.adfweb.com?Product=HD67601
www.adfweb.com?Product=HD67602
www.adfweb.com?Product=HD67602
www.adfweb.com?Product=HD67603
www.adfweb.com?Product=HD67603
www.adfweb.com?Product=HD67604
www.adfweb.com?Product=HD67605
Do you have an your customer protocol?
www.adfweb.com?Product=HD67003
Do you need to choose a device? do you want help?
www.adfweb.com?Cmd=helpme
INFO:
www.adfweb.com
in India
in India
in India
in India
Revision 1.001
Pagina 1 di 22
(CAN)
(DeviceNet Master)
(J1939)
(NMEA2000)
(Serial RS232)
(Serial RS485)
(Modbus Master RS232)
(Modbus Master RS485)
(Modbus Slave RS232)
(Modbus Slave RS485)
(PROFIBUS Master)
(PROFIBUS Slave)
Phone +39.0438.30.91.31
Advertisement
Table of Contents
Related Manuals for ADF Web AXIS HD67609-A1
Summary of Contents for ADF Web AXIS HD67609-A1
- Page 1 User Manual PROFINET / DeviceNet Slave Document code: MN67609_ENG Revision 1.001 Pagina 1 di 22 Industrial Electronic Devices User Manual Revision 1.001 English PROFINET / DeviceNet Slave - Converter (Order Code: HD67609-A1) for Website information: www.adfweb.com?Product=HD67609 for Price information: www.adfweb.com?Price=HD67609-A1 Benefits and Main Features: For others PROFINET products see also the following link: Very easy to configure...
-
Page 2: Table Of Contents
User Manual PROFINET / DeviceNet Slave Document code: MN67609_ENG Revision 1.001 Pagina 2 di 22 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that Page you need to check that the following document is: INDEX Updated UPDATED DOCUMENTATION... -
Page 3: Security Alert
User Manual PROFINET / DeviceNet Slave Document code: MN67609_ENG Revision 1.001 Pagina 3 di 22 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device are required for each individual application, legal and safety regulation. -
Page 4: Example Of Connection
User Manual PROFINET / DeviceNet Slave Document code: MN67609_ENG Revision 1.001 Pagina 4 di 22 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 5: Connection Scheme
User Manual PROFINET / DeviceNet Slave Document code: MN67609_ENG Revision 1.001 Pagina 5 di 22 Industrial Electronic Devices CONNECTION SCHEME: Figure 1: Connection scheme for HD67609-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 6: Characteristics
User Manual PROFINET / DeviceNet Slave Document code: MN67609_ENG Revision 1.001 Pagina 6 di 22 Industrial Electronic Devices CHARACTERISTICS: The HD67609-A1 is a PROFINET / DeviceNet Slave - Converter. It has the following characteristics: Up to 455 bytes in reading and 455 bytes in writing; Triple isolation between DeviceNet - Power Supply, DeviceNet - Ethernet, Power Supply - Ethernet. -
Page 7: Power Supply
User Manual PROFINET / DeviceNet Slave Document code: MN67609_ENG Revision 1.001 Pagina 7 di 22 Industrial Electronic Devices POWER SUPPLY: The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below. Vmin Vmax Vmin Vmax... -
Page 8: Function Modes
User Manual PROFINET / DeviceNet Slave Document code: MN67609_ENG Revision 1.001 Pagina 8 di 22 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending of the position of the ‘Dip2 of Dip-Switch A’: The first, with ‘Dip2 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device. The second, with ‘Dip2 of Dip-Switch A’... -
Page 9: Leds
User Manual PROFINET / DeviceNet Slave Document code: MN67609_ENG Revision 1.001 Pagina 9 di 22 Industrial Electronic Devices LEDS: The device has got six LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode ON: Device powered... -
Page 10: Profinet
User Manual PROFINET / DeviceNet Slave Document code: MN67609_ENG Revision 1.001 Pagina 10 di 22 Industrial Electronic Devices PROFINET: The PROFINET connection must be made using Connector3 and/or Connector4 of HD67609-A1 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. -
Page 11: Can
User Manual PROFINET / DeviceNet Slave Document code: MN67609_ENG Revision 1.001 Pagina 11 di 22 Industrial Electronic Devices DeviceNet: For terminate the DeviceNet line with a 120Ω resistor it is necessary that the Dip1 of ‘Dip-Switch B’ is at ON position. Cable characteristics: DC parameter: Impedance... -
Page 12: Use Of Compositor Sw67609
User Manual PROFINET / DeviceNet Slave Document code: MN67609_ENG Revision 1.001 Pagina 12 di 22 Industrial Electronic Devices USE OF COMPOSITOR SW67609: To configure the Converter, use the available software that runs with Windows, called SW67609. downloadable site www.adfweb.com and its operation is described in this document. (This manual is referenced to the last version of the software present on our web site). -
Page 13: Set Communication
User Manual PROFINET / DeviceNet Slave Document code: MN67609_ENG Revision 1.001 Pagina 13 di 22 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of two buses, PROFINET and DeviceNet. By Pressing the “Set Communication” button from the main window for SW67609 (Fig. 2) the window “Set Communication”... -
Page 14: Update Device
User Manual PROFINET / DeviceNet Slave Document code: MN67609_ENG Revision 1.001 Pagina 14 di 22 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button it is possible to load the created Configuration into the device; and also the Firmware, if is necessary. If you don’t know the actual IP address of the device you have to use this procedure: Turn off the Device;... - Page 15 User Manual PROFINET / DeviceNet Slave Document code: MN67609_ENG Revision 1.001 Pagina 15 di 22 Industrial Electronic Devices If you know the actual IP address of the device you have to use this procedure: Turn on the Device with the Ethernet cable inserted; Insert the actual IP of the Converter;...
-
Page 16: Mechanical Dimensions
User Manual PROFINET / DeviceNet Slave Document code: MN67609_ENG Revision 1.001 Pagina 16 di 22 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 10: Mechanical dimensions scheme for HD67609-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 17: Ordering Informations
User Manual PROFINET / DeviceNet Slave Document code: MN67609_ENG Revision 1.001 Pagina 17 di 22 Industrial Electronic Devices ORDERING INFORMATIONS: The ordering part number is formed by a valid combination of the following: HD67609 – A 1 Connectors Type 1: Removable 5mm Screw Terminal Enclosure Type A: 1M, 35mm DIN Rail mounting Device Family... -
Page 18: Plc Configuration
User Manual PROFINET / DeviceNet Slave Document code: MN67609_ENG Revision 1.001 Pagina 18 di 22 Industrial Electronic Devices PLC CONFIGURATION: The configuration and commissioning of the PROFINET Converter as described on the following pages was accomplished with the help of the TIA Portal V11-software of Siemens. - Page 19 User Manual PROFINET / DeviceNet Slave Document code: MN67609_ENG Revision 1.001 Pagina 19 di 22 Industrial Electronic Devices 2) Import the module in the network; connect the device to the PLC network and edit the parameters of IP, station name etc. ADFweb.com Srl –...
- Page 20 User Manual PROFINET / DeviceNet Slave Document code: MN67609_ENG Revision 1.001 Pagina 20 di 22 Industrial Electronic Devices 3) Load the configuration into the PLC. ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
-
Page 21: Disclaimer
User Manual PROFINET / DeviceNet Slave Document code: MN67609_ENG Revision 1.001 Pagina 21 di 22 Industrial Electronic Devices DISCLAIMER All technical content within this document can be modified without notice. The content of the document content is a recurring audit. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user. -
Page 22: Warranties And Technical Support
User Manual PROFINET / DeviceNet Slave Document code: MN67609_ENG Revision 1.001 Pagina 22 di 22 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following: 1) Obtain a Product Return Number (PRN) from our internet support at www.adfweb.com.
