Industrial Electronic Devices

User Manual

Revision 1.000

English

Modbus Slave / SNMP Agent – Converter

(Order Code: HD674-A009)

For Website information:

www.adfweb.com?Product=HD674-A009

For Price information:

www.adfweb.com?Price=HD674-A009

Benefits and Main Features:

Wide supply input range

Electrical isolation

Industrial temperature range:

-40°C / +105°C (-40°F / +221°F)

User Manual

ADFweb.com Srl – IT31010 – Mareno – Treviso

User Manual Modbus Slave / SNMP Agent

Document code: MN674-A009_ENG

Page 1 of 31

For others Gateways / Bridges:

J1939 to Modbus

Need help?

Do you have a question about the HD674-A009 and is the answer not in the manual?

Questions and answers

Summary of Contents for ADF Web HD674-A009

Page 1 Revision 1.000 Page 1 of 31 Page 1 of 31 Industrial Electronic Devices User Manual Revision 1.000 English Modbus Slave / SNMP Agent – Converter (Order Code: HD674-A009) For Website information: www.adfweb.com?Product=HD674-A009 For others Gateways / Bridges: For Price information: J1939 to Modbus www.adfweb.com?Price=HD674-A009 See also the following links: www.adfweb.com?Product=HD67212...
Page 2: Updated Documentation
User Manual Modbus Slave / SNMP Agent Document code: MN674-A009_ENG Revision 1.000 Page 2 of 31 Page 2 of 31 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that Page you need to check that the following document is: INDEX UPDATED DOCUMENTATION...
Page 3: Security Alert
User Manual Modbus Slave / SNMP Agent Document code: MN674-A009_ENG Revision 1.000 Page 3 of 31 Page 3 of 31 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application.
Page 4: Example Of Connection
User Manual Modbus Slave / SNMP Agent Document code: MN674-A009_ENG Revision 1.000 Page 4 of 31 Page 4 of 31 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 5: Connection Scheme
User Manual Modbus Slave / SNMP Agent Document code: MN674-A009_ENG Revision 1.000 Page 5 of 31 Page 5 of 31 Industrial Electronic Devices CONNECTION SCHEME: Figure 1a: Connection scheme for HD674-A009-2-E4x-xx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 6 User Manual Modbus Slave / SNMP Agent Document code: MN674-A009_ENG Revision 1.000 Page 6 of 31 Page 6 of 31 Industrial Electronic Devices Figure 1b: Connection scheme for HD674-A009-2-E7x-xx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 7 User Manual Modbus Slave / SNMP Agent Document code: MN674-A009_ENG Revision 1.000 Page 7 of 31 Page 7 of 31 Industrial Electronic Devices Figure 1c: Connection scheme for HD674-A009-4-E4x-xx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 8 User Manual Modbus Slave / SNMP Agent Document code: MN674-A009_ENG Revision 1.000 Page 8 of 31 Page 8 of 31 Industrial Electronic Devices Figure 1d: Connection scheme for HD674-A009-4-E7x-xx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 9 Industrial Electronic Devices CHARACTERISTICS: The “HD674-A009” series are rugged devices used to interface a SNMP Manager with a Modbus Master. With its particular enclosure, equipped with four fixing lugs, makes available the mounting of the device in any plane surface (horizontal, vertical, oblique).
Page 10: Power Supply
POWER SUPPLY: The devices can be powered between a wide range of tensions. For more details see the two tables below. Vmin Vmax Vmin Vmax HD674-A009-Exx-xx Consumption at 24V DC: Device W/VA HD674-A009-Exx-xx Caution: Not reverse the polarity power HD674-A009-E4x-xx HD674-A009-E7x-xx Note: It is possible to use also negative tensions.
Page 11 User Manual Modbus Slave / SNMP Agent Document code: MN674-A009_ENG Revision 1.000 Page 11 of 31 Page 11 of 31 Industrial Electronic Devices LEDS: The device has got four LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below.
Page 12 Page 12 of 31 Industrial Electronic Devices RS232: The connection of the RS232 in the HD674-A009-2-E4x-xx device must be made with a 3way MiniFit Female connector. The pinout of Male MiniFit connector of the board is at right side of the page.
Page 13 Page 13 of 31 Industrial Electronic Devices RS485: The connection of the RS485 in the HD674-A009-4-E4x-xx device must be made with a 3way MiniFit Female connector. The pinout of Male MiniFit connector of the board is at right side of the page.
Page 14 ETHERNET: The connection of Ethernet in the HD674-A009 device must be made with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To connect the device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC/PLC/other is recommended the use of a cross cable.
Page 15 User Manual Modbus Slave / SNMP Agent Document code: MN674-A009_ENG Revision 1.000 Page 15 of 31 Page 15 of 31 Industrial Electronic Devices USE OF COMPOSITOR SW674-A009: To configure the Converter, use the available software that runs with Windows called SW674-A009. It is downloadable on the site www.adfweb.com and its operation is described in this document.
Page 16: New Configuration / Open Configuration
User Manual Modbus Slave / SNMP Agent Document code: MN674-A009_ENG Revision 1.000 Page 16 of 31 Page 16 of 31 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a programmable “Modbus Slave / SNMP Agent - Converter”...
Page 17: Software Options
User Manual Modbus Slave / SNMP Agent Document code: MN674-A009_ENG Revision 1.000 Page 17 of 31 Page 17 of 31 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor.
Page 18: Set Communication
User Manual Modbus Slave / SNMP Agent Document code: MN674-A009_ENG Revision 1.000 Page 18 of 31 Page 18 of 31 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of two buses, Modbus and SNMP. By Pressing the “Set Communication”...
Page 19: Set Snmp Access
User Manual Modbus Slave / SNMP Agent Document code: MN674-A009_ENG Revision 1.000 Page 19 of 31 Page 19 of 31 Industrial Electronic Devices SET SNMP ACCESS: By pressing the “Set SNMP Access” button from the main window for SW674-A009 (Fig. 2) the “Set SNMP Access” window appears (Fig. 4).
Page 20 User Manual Modbus Slave / SNMP Agent Document code: MN674-A009_ENG Revision 1.000 Page 20 of 31 Page 20 of 31 Industrial Electronic Devices The data of the columns in the “SNMP Write” have the following meanings: field “Enable” checked, the SNMP OID is enabled;...
Page 21: Update Device
User Manual Modbus Slave / SNMP Agent Document code: MN674-A009_ENG Revision 1.000 Page 21 of 31 Page 21 of 31 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device;...
Page 22 Windows Vista, Seven, 8, 10 or 11 you have to launch the Figure 6: “Protection” window "Command Prompt" with Administrator Rights; Pay attention at Firewall lock. In the case of HD674-A009 you have to use the software “SW674-A009”: www.adfweb.com\download\filefold\SW674-A009.zip. ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com...
Page 23: Modbus Map
User Manual Modbus Slave / SNMP Agent Document code: MN674-A009_ENG Revision 1.000 Page 23 of 31 Page 23 of 31 Industrial Electronic Devices MODBUS MAP: On Modbus side, the map is created automatically. In relation to the configuration defined, it is possible to have two different maps. Data in reading: Type Address...
Page 24: Mechanical Dimensions
User Manual Modbus Slave / SNMP Agent Document code: MN674-A009_ENG Revision 1.000 Page 24 of 31 Page 24 of 31 Industrial Electronic Devices MECHANICAL DIMENSIONS: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 25 User Manual Modbus Slave / SNMP Agent Document code: MN674-A009_ENG Revision 1.000 Page 25 of 31 Page 25 of 31 Industrial Electronic Devices Type A ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 26 User Manual Modbus Slave / SNMP Agent Document code: MN674-A009_ENG Revision 1.000 Page 26 of 31 Page 26 of 31 Industrial Electronic Devices Type B ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 27 User Manual Modbus Slave / SNMP Agent Document code: MN674-A009_ENG Revision 1.000 Page 27 of 31 Page 27 of 31 Industrial Electronic Devices Type C ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 28: Ordering Informations
Varnished/Resinated V: Varnished R: Resined Connectors Type 4: MiniFit 7: SuperSeal 1.5 Enclosure Type E: Metal enclosure Device Family HD674-A009 = Modbus Slave / SNMP Agent - Converter ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 29 User Manual Modbus Slave / SNMP Agent Document code: MN674-A009_ENG Revision 1.000 Page 29 of 31 Page 29 of 31 Industrial Electronic Devices ACCESSORIES: Order Code: AC34011 35mm Rail DIN - Power Supply 220/240V AC 50/60Hz – 12 V DC Order Code: AC34012 35mm Rail DIN - Power Supply 220/240V AC 50/60Hz –...
Page 30 User Manual Modbus Slave / SNMP Agent Document code: MN674-A009_ENG Revision 1.000 Page 30 of 31 Page 30 of 31 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user.
Page 31: Warranties And Technical Support
User Manual Modbus Slave / SNMP Agent Document code: MN674-A009_ENG Revision 1.000 Page 31 of 31 Page 31 of 31 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
