Industrial Electronic Devices
User Manual
Revision 1.002
English
Gateway / Adapter
J1939 to Ethernet
(Order Code: HD67213 – HD67213M)
for Website information:
www.adfweb.com?Product=HD67213
www.adfweb.com?Product=HD67213M
for Price information:
www.adfweb.com?Price=HD67213
www.adfweb.com?Price=HD67213M
Benefits and Main Features:
Mountable on Rail DIN
TCP/UDP protocols changeable with software
Easy to use software configuration
Industrial temperature range:
-30 °C / 70°C (-22°F / 158°F)
ADFweb.com Srl – IT31010 – Mareno – Treviso
User Manual J1939 to Ethernet
Document code: MN67213_ENG
HD67213
Similiar
For others Converter / Adapter:
Products
RS232 / RS485
See also the following link:
www.adfweb.com?Product=HD67118
USB / RS485
See also the following link:
www.adfweb.com?Product=HD67119
Do you have an your customer protocol?
See the following link:
www.adfweb.com?Product=HD67003
Do you need to choose a device? do you want help?
Ask it to the following link:
www.adfweb.com?Cmd=helpme
INFO:
www.adfweb.com
Revision 1.002
Page 1 of 16
HD67213M
Phone +39.0438.30.91.31
Advertisement
Table of Contents
Related Manuals for ADF Web J1939 to Ethernet
Summary of Contents for ADF Web J1939 to Ethernet
- Page 1 User Manual J1939 to Ethernet Document code: MN67213_ENG Revision 1.002 Page 1 of 16 Industrial Electronic Devices User Manual Revision 1.002 English Gateway / Adapter J1939 to Ethernet (Order Code: HD67213 – HD67213M) for Website information: www.adfweb.com?Product=HD67213 www.adfweb.com?Product=HD67213M HD67213 HD67213M for Price information: www.adfweb.com?Price=HD67213...
-
Page 2: Table Of Contents
User Manual J1939 to Ethernet Document code: MN67213_ENG Revision 1.002 Page 2 of 16 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that you need to check that the following document is:... -
Page 3: Connection Scheme
User Manual J1939 to Ethernet Document code: MN67213_ENG Revision 1.002 Page 3 of 16 Industrial Electronic Devices CONNECTION SCHEME: Figure 1: Connection scheme HD67213 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... - Page 4 User Manual J1939 to Ethernet Document code: MN67213_ENG Revision 1.002 Page 4 of 16 Industrial Electronic Devices Figure 2: Connection scheme for HD67213M ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
-
Page 5: Characteristics
User Manual J1939 to Ethernet Document code: MN67213_ENG Revision 1.002 Page 5 of 16 Industrial Electronic Devices CHARACTERISTICS: The Configurable J1939 Slave to Ethernet gateway allow the following: TCP/UDP Ethernet protocols changeable with software; Mountable on Rail DIN; Temperature range -30°C to 70°C. -
Page 6: Confuguration
User Manual J1939 to Ethernet Document code: MN67213_ENG Revision 1.002 Page 6 of 16 Industrial Electronic Devices CONFIGURATION: You need Compositor SW67213 software on your PC in order to perform the following: Define the parameter of the J1939 bus; Define the parameter of the Ethernet;... -
Page 7: New Project / Open Project
A device configuration can also be imported and exported: To clone the configurations of a Programmable J1939 to Ethernet Gateway in order to configure another device in the same manner, it is necessary to maintain the folder and all its contents;... -
Page 8: Set Communication
User Manual J1939 to Ethernet Document code: MN67213_ENG Revision 1.002 Page 8 of 16 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameter of two buses, J1939 and Ethernet. By pressing the “Set Communication” button from the main window for SW67213 (Fig. 3) the window “Set Communication”... -
Page 9: Receive J1939
User Manual J1939 to Ethernet Document code: MN67213_ENG Revision 1.002 Page 9 of 16 Industrial Electronic Devices RECEIVE J1939 By pressing the “Receive COB” button from the main window for SW67513 (Fig. 3) the window “Receive CAN Frame” appears (Fig. 5). -
Page 10: Update Via Tcp
User Manual J1939 to Ethernet Document code: MN67213_ENG Revision 1.002 Page 10 of 16 Industrial Electronic Devices UPDATE DEVICE VIA TCP: Section “Update Via TCP” (Fig. 6): In order to load the parameters or update the firmware in the gateway, follow these instructions: Connect the Ethernet cable from your PC to the gateway;... -
Page 11: Update Via Serial
User Manual J1939 to Ethernet Document code: MN67213_ENG Revision 1.002 Page 11 of 16 Industrial Electronic Devices UPDATE DEVICE VIA SERIAL Section “Update Via Serial” (Fig. 7): In order to load the parameters or update the firmware in the gateway, follow these instructions: Turn off the device;... -
Page 12: Characteristics Of The Cables
User Manual J1939 to Ethernet Document code: MN67213_ENG Revision 1.002 Page 12 of 16 Industrial Electronic Devices CHARACTERISTICS OF THE CABLES: The connection at Ethernet socket must be with a Ethernet Cable with a RJ45 Plug The connection from RS232 socket to a serial port (example one from a personal computer), must be made with a Null Modem cable (a serial cable where the pins 2 and 3 are crossed). -
Page 13: Ethernet Protocol
User Manual J1939 to Ethernet Document code: MN67213_ENG Revision 1.002 Page 13 of 16 Industrial Electronic Devices ETHERNET PROTOCOL This protocol is able to read and write frames in the J1939 net. Write Frames The transmission is very simple, it require only what are the packets to send. In a single request it is possible to write at maximum 19 frames in the J1939 net. -
Page 14: Read Fames
User Manual J1939 to Ethernet Document code: MN67213_ENG Revision 1.002 Page 14 of 16 Industrial Electronic Devices Read Frames For reading Data it is necessary to have a map in the RAM memory that contains the Data that passing in the bus. This map is implemented in the “Compositor SW67213”... -
Page 15: Mechanical Dimensions
User Manual J1939 to Ethernet Document code: MN67213_ENG Revision 1.002 Page 15 of 16 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 8: Mechanical dimensions scheme for HD67213 Figure 9: Mechanical dimensions scheme for HD67213M ORDER CODE: Order Code: HD67213 Gateway – J1939 to Ethernet... -
Page 16: Warranties And Technical Support
User Manual J1939 to Ethernet Document code: MN67213_ENG Revision 1.002 Page 16 of 16 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com...
