ADF Web AXIS HD67165-232-A1 User Manual

Modbus slave / snmp converter
Hide thumbs

Advertisement

Quick Links

Download this manual
Industrial Electronic Devices
User Manual
Revision 1.000
English
Modbus Slave / SNMP - Converter
(Order Code: HD67165-232-A1, HD67165-485-A1,
HD67165-422-A1, HD67165-232-485-A1, HD67165-232-422-A1,
HD67165-232-B2, HD67165-485-B2, HD67165-232-485-B2)
for Website information:
www.adfweb.com?Product=HD67165
for Price information:
www.adfweb.com?Price=HD67165-232-A1
www.adfweb.com?Price=HD67165-485-A1
www.adfweb.com?Price=HD67165-422-A1
www.adfweb.com?Price=HD67165-232-485-A1
www.adfweb.com?Price=HD67165-232-422-A1
www.adfweb.com?Price=HD67165-232-B2
www.adfweb.com?Price=HD67165-485-B2
www.adfweb.com?Price=HD67165-232-485-B2
Benefits and Main Features:
Very easy to configure
Electrical isolation
Temperature range: -40°C/85°C (-40°F/185°F)
User Manual
ADFweb.com Srl – IT31010 – Mareno – Treviso
Axis Solutions Pvt Ltd is the Authorized Distributor of
www.axisindia.in | info@axisindia.in
User Manual Modbus Slave / SNMP
Document code: MN67165_ENG
For others SNMP products, see also the following links:
Converter SNMP to
www.adfweb.com?Product=HD67155
www.adfweb.com?Product=HD67156
www.adfweb.com?Product=HD67159
www.adfweb.com?Product=HD67160
www.adfweb.com?Product=HD67161
www.adfweb.com?Product=HD67162
www.adfweb.com?Product=HD67163
www.adfweb.com?Product=HD67164
www.adfweb.com?Product=HD67166
www.adfweb.com?Product=HD67167
www.adfweb.com?Product=HD67168
www.adfweb.com?Product=HD67169
www.adfweb.com?Product=HD67613
www.adfweb.com?Product=HD67693
www.adfweb.com?Product=HD67726
Do you have an your customer protocol?
www.adfweb.com?Product=HD67003
Do you need to choose a device? do you want help?
www.adfweb.com?Cmd=helpme
INFO:
www.adfweb.com
in India
Revision 1.000
Pagina 1 di 32
(CAN)
(CANopen)
(EtherNet/IP)
(DeviceNet Master)
(DeviceNet Slave)
(J1939)
(M-Bus Master)
(Modbus Master)
(Modbus TCP Master)
(Modbus TCP Slave)
(PROFIBUS Master)
(PROFIBUS Slave)
(PROFINET)
(BACnet Slave)
(BACnet Master)
Phone +39.0438.30.91.31

Advertisement

loading
Need help?

Need help?

Do you have a question about the AXIS HD67165-232-A1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ADF Web AXIS HD67165-232-A1

Summary of Contents for ADF Web AXIS HD67165-232-A1

  • Page 1 User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 1 di 32 Industrial Electronic Devices User Manual Revision 1.000 English Modbus Slave / SNMP - Converter (Order Code: HD67165-232-A1, HD67165-485-A1, HD67165-422-A1, HD67165-232-485-A1, HD67165-232-422-A1, HD67165-232-B2, HD67165-485-B2, HD67165-232-485-B2) for Website information: www.adfweb.com?Product=HD67165 for Price information: www.adfweb.com?Price=HD67165-232-A1...

  • Page 2: Updated Documentation

    User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 2 di 32 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that Page you need to check that the following document is: INDEX UPDATED DOCUMENTATION Updated...

  • Page 3: Security Alert

    User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 3 di 32 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application.

  • Page 4: Example Of Connection

    User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 4 di 32 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...

  • Page 5: Connection Scheme

    User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 5 di 32 Industrial Electronic Devices CONNECTION SCHEME: Figure 1a: Connection scheme for HD67165-232-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
  • Page 6 User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 6 di 32 Industrial Electronic Devices Figure 1b: Connection scheme for HD67165-485-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
  • Page 7 User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 7 di 32 Industrial Electronic Devices Figure 1c: Connection scheme for HD67165-422-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
  • Page 8 User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 8 di 32 Industrial Electronic Devices Figure 1d: Connection scheme for HD67165-232-485-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
  • Page 9 User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 9 di 32 Industrial Electronic Devices Figure 1e: Connection scheme for HD67165-232-422-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
  • Page 10 User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 10 di 32 Industrial Electronic Devices Figure 1f: Connection scheme for HD67165-232-B2 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
  • Page 11 User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 11 di 32 Industrial Electronic Devices Figure 1g: Connection scheme for HD67165-485-B2 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
  • Page 12 User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 12 di 32 Industrial Electronic Devices Figure 1g: Connection scheme for HD67165-232-485-B2 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
  • Page 13 User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 13 di 32 Industrial Electronic Devices CHARACTERISTICS: The HD67165-A1 and HD67165-B2 is a Modbus Slave / SNMP - Converter. It has the following characteristics: Up to 1024 bytes in reading and 1024 bytes in writing; Triple isolation between Serial - Power Supply, Serial - Ethernet, Power Supply - Ethernet.

  • Page 14: Power Supply

    User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 14 di 32 Industrial Electronic Devices POWER SUPPLY: The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below. Vmin Vmax Vmin Vmax...

  • Page 15: Function Modes

    User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 15 di 32 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending of the position of the ‘Dip2 of Dip-Switch A’: The first, with ‘Dip2 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device. The second, with ‘Dip2 of Dip-Switch A’...
  • Page 16 User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 16 di 32 Industrial Electronic Devices LEDS: The devices have got four (five for HD67165-B2) LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state...
  • Page 17 User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 17 di 32 Industrial Electronic Devices SNMP: The SNMP connection must be made using Connector5 of HD67165-A1/B2 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m.
  • Page 18 User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 18 di 32 Industrial Electronic Devices RS485: For terminate the RS485 line with a 220Ω resistor it is necessary to put ON dip 1, like in figure. The maximum length of the cable should be 1200m (4000 feet). Here some codes of cables: Belden: p/n 8132 - 2x 28AWG stranded twisted pairs conductor + foil shield + braid shield;...
  • Page 19 User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 19 di 32 Industrial Electronic Devices RS422: For terminate the RS485 line with a 220Ω resistor it is necessary to put ON dip 1 for T line and/or put ON dip 2 for R line, like in figure. The maximum length of the cable should be 1200m (4000 feet).
  • Page 20 User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 20 di 32 Industrial Electronic Devices USE OF COMPOSITOR SW67165: To configure the Converter, use the available software that runs with Windows called SW67165. It is downloadable on the site www.adfweb.com and its operation is described in this document.

  • Page 21: New Configuration / Open Configuration

    User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 21 di 32 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a Programmable “Modbus Slave / SNMP - Converter”...

  • Page 22: Software Options

    User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 22 di 32 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor.

  • Page 23: Set Communication

    User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 23 di 32 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of two buses, SNMP and Modbus. By Pressing the “Set Communication” button from the main window for SW67165 (Fig. 2) the window “Set Communication”...

  • Page 24: Update Device

    User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 24 di 32 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary.
  • Page 25 User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 25 di 32 Industrial Electronic Devices If you know the actual IP address of the device, you have to use this procedure: Turn on the Device with the Ethernet cable inserted; Insert the actual IP of the Converter;...

  • Page 26: Snmp Communication

    User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 26 di 32 Industrial Electronic Devices SNMP COMMUNICATION In order to read/write the data from/to Modbus side, it is necessary to use specific SNMP commands in order to see the SNMP Input and write the SNMP Output.
  • Page 27 User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 27 di 32 Industrial Electronic Devices Writing Modbus data from SNMP: In order to write the data to the HD67165-A1/B2 it is necessary to use the “snmpset” command. The Output array is contained to this internal directory: 1.3.6.1.4.1.33118.1.1.1.4.x.0, where ‘x’...

  • Page 28: Mechanical Dimensions

    User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 28 di 32 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 7a: Mechanical dimensions scheme for HD67165-xxx-A1 Figure 7b: Mechanical dimensions scheme for HD67165-xxx-B2 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...

  • Page 29: Ordering Informations

    User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 29 di 32 Industrial Electronic Devices ORDERING INFORMATIONS: The ordering part number is formed by a valid combination of the following: HD67165 - xxx – x x Connectors Type 1: Removable 5mm Screw Terminal 2: Fixed 5mm Screw Terminal Enclosure Type...
  • Page 30 User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 30 di 32 Industrial Electronic Devices ACCESSORIES: Order Code: AC34001 35mm Rail DIN - Power Supply 220/240V AC 50/60Hz – 12 V AC Order Code: AC34002 35mm Rail DIN - Power Supply 110V AC 50/60Hz – 12 V AC ADFweb.com Srl –...
  • Page 31 User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 31 di 32 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user.

  • Page 32: Warranties And Technical Support

    User Manual Modbus Slave / SNMP Document code: MN67165_ENG Revision 1.000 Pagina 32 di 32 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following: Obtain a Product Return Number (PRN) from our internet support at www.adfweb.com.

This manual is also suitable for:

Axis hd67165-485-a1Axis hd67165-422-a1Axis hd67165-232-485-a1Axis hd67165-232-422-a1Axis hd67165-232-b2Axis hd67165-485-b2 ... Show all
