ADF Web HD67879-A1-XX User Manual

Io-link master / ethercat slave
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Industrial Electronic Devices
User Manual
Revision 1.000
English
IO-Link Master / EtherCAT Slave -
Converter
(Order Code: HD67879-A1-XX)
for Website information:
www.adfweb.com/?Product=HD67879
for Price information:
www.adfweb.com/?Price=HD67879-A1-2A
www.adfweb.com/?Price=HD67879-A1-4A
www.adfweb.com/?Price=HD67879-A1-2A-2B
www.adfweb.com/?Price=HD67879-A1-2B
www.adfweb.com/?Price=HD67879-A1-4B
www.adfweb.com/?Price=HD67879-A1-4A-4B
www.adfweb.com/?Price=HD67879-A1-8A
Benefits and Main Features:
Triple electrical isolation
Two Ethernet ports
Temperature range: -40°C/+85°C (-40°F/+185°F)
User Manual
ADFweb.com Srl – IT31010 – Mareno – Treviso
User Manual IO-Link Master / EtherCAT Slave
Document code: MN67879_ENG
For others IO-Link devices, see also the following links:
IO-Link from/to ...
www.adfweb.com?Product=HD67860
www.adfweb.com?Product=HD67861
www.adfweb.com?Product=HD67862
www.adfweb.com?Product=HD67864
www.adfweb.com?Product=HD67864
www.adfweb.com?Product=HD67865
www.adfweb.com?Product=HD67866
www.adfweb.com?Product=HD67867
www.adfweb.com?Product=HD67868
www.adfweb.com?Product=HD67869
www.adfweb.com?Product=HD67870
www.adfweb.com?Product=HD67871
www.adfweb.com?Product=HD67872
www.adfweb.com?Product=HD67873
www.adfweb.com?Product=HD67874
www.adfweb.com?Product=HD67875
www.adfweb.com?Product=HD67876
www.adfweb.com?Product=HD67877
www.adfweb.com?Product=HD67878
Do you have an your customer protocol?
See the following links:
www.adfweb.com?Product=HD67879
Do you need to choose a device? do you want help?
Ask it to the following link:
www.adfweb.com?Cmd=helpme
INFO:
www.adfweb.com
Revision 1.000
Page 1 of 44
(Modbus Master)
(Modbus Slave)
(Modbus TCP Master)
(Modbus TCP Slave)
(BACnet Master)
(BACnet Slave)
(CAN)
(CANopen)
(DeviceNet Master)
(DeviceNet Slave)
(EtherNet/IP Master)
(EtherNet/IP Slave)
(J1939)
(MQTT)
(NMEA0183)
(NMEA2000)
(PROFINET Slave)
(SNMP Manager)
(SNMP Agent)
Phone +39.0438.30.91.31

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HD67879-A1-XX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ADF Web HD67879-A1-XX

Summary of Contents for ADF Web HD67879-A1-XX

  • Page 1 Revision 1.000 Page 1 of 44 User Manual Revision 1.000 English IO-Link Master / EtherCAT Slave - Converter (Order Code: HD67879-A1-XX) for Website information: www.adfweb.com/?Product=HD67879 For others IO-Link devices, see also the following links: IO-Link from/to … for Price information: www.adfweb.com?Product=HD67860 (Modbus Master) www.adfweb.com/?Price=HD67879-A1-2A...
