5.3 Sensor

This option is used to calibrate the selected sensor. We recommend calibrate the sensor before printing when changing the media.
Menu
Item
Auto Calibration Set the media sensor type and calibrate the selected sensor automatically.
Preprint Calibration Calibrate the preprint labels.
In case Auto Calibration does not work, please use "Manual" function to set the paper length and
Manual Calibration
gap/bline size to complete the calibration setting.
Threshold Detect Set sensor sensitivity in fixed or auto.
Maximum Length Set the maximum length for label calibration.
Gap Location Determine which gap sensor as the main gap sensor.
Auto Calibration
Preprint Calibration
Manual Calibration
Sensor
Threshold Detect
Gap Location
Blackmark Location
Maximum Length
Cover Error
Advanced
Description
Gap
Black Mark
Continuous
Gap
Black Mark
Gap
Black Mark
Continuous
Auto
Fixed
Min. Paper
Max. Gap/Mark
Default
761mm
N/A
N/A
N/A
Auto
Rear
