Overview

Key

Pictogram | Definition
Danger/Warning/Caution
Note
To be complied with
Load-bearing point
Visual inspection
Tip
Incorrect use
Safety helmet
Safety shoes
Safety gloves
Safety goggles
Personal protective equipment
to prevent falling from a height
(PPE)
Arrows
Arrow representing an action
Arrow representing a reaction
of an action*
Arrow representing forces
* If not identical to the action arrow.
SKYMAX Panel Slab Formwork
Instructions for Assembly and Use – Standard Configuration
Safety instruction categories
The safety instructions alert site
personnel to the risks involved and
provide information on how to avoid
these risks. Safety instructions can be
found at the beginning of the section or
before instructions for action and are
highlighted as follows:
Danger
This sign indicates an extremely
hazardous situation which could result
in death or serious, irreversible injury, if
the safety instructions are not followed.
Warning
This sign indicates a hazardous
situation which could result in death or
serious, irreversible injury, if the safety
instructions are not followed.
Caution
This sign indicates a hazardous
situation which could result in minor or
moderate injury, if the safety
instructions are not followed.
Note
This sign indicates situations in which
failure to observe the information can
result in material damage.
Format of the safety instructions
Signal word
Type and source of hazard!
Consequences of non-compliance.
⇒ Preventative measures.
Dimensions
Dimensions are usually given in cm.
Other measurement units, e.g. m,
are shown in the illustrations.
Conventions
■
Instructions are numbered with:
1. ....., 2. ....., 3. ......
■
The result of an instruction is
shown by: →
■
Position numbers are clearly provided
for the individual components and
are given in the drawing, e.g. 1, in
the text in brackets, for example (1).
■
Multiple position numbers, i.e.
alternative components, are
represented with a slash: e.g. 1/2.
Notes on illustrations
The illustration on the front cover of
these instructions is understood to be
a system representation only. The
assembly steps presented in these
Instructions for Assembly and Use are
shown in the form of examples with
only one component size. They are valid
for all component sizes contained in the
standard configuration.
To facilitate understanding, detailed
illustrations are sometimes incomplete.
The safety equipment which has
possibly not been shown in these
detailed illustrations must nevertheless
be available.
5
