Peri SKYMAX Instructions For Assembly And Use page 162

SKYMAX Panel Slab Formwork
Item no. Weight kg
136869 7.580 Lowering Head SXP LQ
102120 0.030 Bolt ISO 4017 M12 x 30-8.8, galv.
710330 0.017 Nut ISO 4032 M12-8, galv.
Support Head SXP S
133701 2.500
Head for all positions with quick-release fastener.
133855 1.040 Support Head SXP S Poly
For panels made of aluminum and polymer.
162
172
133
55
L
30
L
M 8
SW 13
174
133
38 38 54
183
134
38 38 54
231
54
233
163
54
222
162
54
