proportions on an NTSC or PAL monitor, select the 16:9 display setting on
the monitor.
If the Pulldown Method list is available, select the pulldown method you
5
want to be applied to your output video ( Standard 2:3 or Advanced
2:3:3:2 ). You should select Advanced 2:3:3:2 only if you'll be recording
to a DV-1394 device that supports this pulldown method. Depending on your
sequence's frame rate and the current master output format, a pulldown
method may automatically be selected.
6 Under Analog Setup (NTSC) , select the setup level you want for your
NTSC analog video:
0 IRE Applies a setup level of 0 IRE. You should select this option only
$
when working with a commercial DV-1394 device that uses the Japanese
analog NTSC setup of 0 IRE. For example, if the video appears too bright
when you play back DV clips on your NTSC monitor, you can change the
setup to 0 IRE to output your DV clips at the correct brightness.
7.5 IRE Applies the standard NTSC setup level of 7.5 IRE.
$
Select Allow Super White to allow the highest luminance level of your
7
video output to exceed the standard maximum white level. Select Allow
Super Black
below the standard black level.
¦ Note
Super white and super black should not be allowed when producing
your final video production for broadcast.
Under Component Gain , use the sliders to increase or decrease the Y
8
(luminance), Cb (blue minus luminance), and Cr (red minus luminance) gain
of the component video output.
Under Advanced Settings , select the format you want for your component
9
video output, and make any required timing adjustments to your SDI video
output:
Component Output Format
$
) that matches your component video output connections. For example,
RGB
if the component video output from X.linkHD is connected to a video
monitor using analog component Y, R-Y, and B-Y, connections, select YUV .
SDI Horizontal Delay
$
timing of the SDI video output.
Click OK to save your settings and return to the Sequence Settings dialog
10
box.
to allow the lowest luminance level of your video output to fall
Use this slider to advance or delay the horizontal
From this list, select the format ( YUV or
Defining your sequence settings
