CY3240-I2USB BRIDGE KIT
QUICK START GUIDE
I2C-USB Bridge Kit Details
Internal Power Jumper
USB Mini-B Connector
Photo Diode
Output LEDs
PSoC CY8C24894 Chip
ISSP Programming Header
PSoC CY8C21123 Chip
GPIO Pins
For the latest information about this kit visit
www.cypress.com/go/CY3240-I2USB
© 2011 Cypress Semiconductor Corporation. All rights reserved. All trademarks or registered trademarks
referenced herein are the properties of their respective owners.
DOC#: 001-66748 REV **
