1
Insert I2C-USB Bridge Kit CD. Install kit
contents, PSoC Designer, PSoC Programmer
and Bridge Control Panel.
3
Connect the USB A to Mini B Cable and
the bridge to PC. LED D2(green) lights up.
5
Provide input for bridge control panel.
Downloaded from
Elcodis.com
electronic components distributor
CY3240-I2USB BRIDGE KIT
QUICK START GUIDE
2
Remove I2C-USB Bridge from package.
4
Plug in the I2C slave demo target board
to header J3 of the bridge board.
6
LED D3 (red) of demo target board
lights up.
