9. Machine Parameters

9.1 Technical Data – Inverters
Model – RI-ENERGYFLOW-MODULAR
Max. PV-generator power
Max. DC Voltage
Nominal voltage
MPPT Voltage Range
Start-up Voltage
Max. DC current (Input A / Input B)
Numbers of MPPT
Strings per MPPT
Max. Short-circuit current per MPPT
Type of DC Connector
Nominal AC power
Max. Input current
Max. AC Power
Max. AC Current
Nominal AC Voltage
Grid frequency/ range
Output Power factor
Output THDi (@Nominal Output)
Max. Output Apparent Power
Nominal Output Voltage
Nominal Output Frequency
Model – RI-ENERGYFLOW-MODULAR
(2) Check whether the load is in compliance with the
specification;
(1) Check PV string for direct or indirect grounding
phenomenon;
W10 (2) Check peripherals of machine for current leakage;
(3) Contact the local inverter customer service if fault
remains unremoved.
(1) Check whether the installation follows the
instructions;
W11
(2) Contact customer service if error warning
continues.
(1) Restart the inverter and wait until it functions
normally.
W12
(2) Contact customer service if error warning
continues.
W14~W25 (1) Please contact the distributor.
PV input data
4800W (2400W per MPPT) 6500W (3250W per MPPT)
AC Output data (On-gird)
AC Output data (Back-up)
AC Output data (Back-up)
Telephone : +44 (0) 1245 428500
Email : sales@rayleigh.com
3.68kW
580V
400V
120...550V
130V
15A / 15A
2
1
18A
MC4
3680W
32A
3680W
16A
230V
50/60Hz (±5Hz), (adjustable)
0.8 leading ~ 0.8 lagging (adjustable)
<3%
4000VA
230V (Fluctuation range ±0.2%)
50/60Hz (Fluctuation range ±0.2%)
3.68kW
5.0kW
5000W
5000W
22A
5000VA
5.0kW
