2.4 Getting Started: Included Accessories and Wiring Kits

Included Accessories
Inverter Module Accessories:
4off M5x12mm Screws
2off Mounting Screws 1off CT/ Meter Connector
and Nylon Wall Plugs
Battery Module Accessories:
4off Mounting Screws
and Nylon Wall Plugs
**An additional wiring kit will be required if the installation contains more than one battery module. Refer to table below.
Wiring Kits for Additional Battery Modules:
Total Number Of Battery Modules
2 pairs of MC4 plugs
(4Way)
3off M5x12mm Screws
2
3
4
1off WIFI Module 1off AC Grid Connector
and 2.5mm Allen Key
1off DRM Connector
(6Way)
4off M6 Flat Washers
1off Back-up Connector
1off Wall Bracket 1off Current Transformer
1off Wall Bracket
Wiring Kit Part Number
RI-MOD-KIT10.2
RI-MOD-KIT15.3
RI-MOD-KIT20.4
Wiring Kit **
