Three battery installation using wiring kit RI-MOD-KIT15.3
Four battery installation using wiring kit RI-MOD-KIT20.4
Communication Cables:
1x
300mm
1x
570mm
1x
1x
1700mm
Power Cables (Black):
1x
250mm
1x
485mm
1x
1800mm
Power Cables (Red):
1x
485mm
1x
1900mm
1x
2800mm
PE Cables:
1x
520mm
1x
700mm
1x
1700mm
Communication Cables:
1x
300mm
2x
570mm
1x
1700mm
Power Cables (Black):
1x
250mm
2x
485mm
1x
1800mm
Power Cables (Red):
2x
485mm
1x
1900mm
1x
3300mm
PE Cables:
2x
520mm
1x
700mm
1x
1700mm
Page 14
