7. Alarm code and error code

7.1 Alarm Code

7.2 Error Code

Codes
W00
W01
W02
W03
W04
W05
W06
W07
W08
W09
W10
W11
W12
W13
W14
W15
W16
W17
Codes
W18
W19
W20
W21
W22
W23
W24
W25
Codes
F00
F01
F02
F04
F05
F06
F07
F08
F09
F10
F11
F12
Telephone : +44 (0) 1245 428500
Email : sales@rayleigh.com
Description
Grid Volt Low
Grid Volt High
Grid Frequency Low
Grid Frequency High
Solar Loss
Bat Loss
Bat Under Volt
Bat Volt Low
Bat Volt High
Over Load
GFCI Over
LN Reverse
Fan Fault
BAT Power Down
BMS Discharge Over Current
BMS charge Over Current
BMS Over Volt
BMS Over Temp
Description
BMS Discharge Low Temp
BMS Volt Imbalance
BMS Communicate Fault
BMS Under Volt
BMS Chg Temp Low
BMS Severe Over Volt
BMS Severe Over Temp
CT Reverse
Description
Soft Time Out
INV Volt Short
GFCI Sensor Fault
Bus Volt Low
Bus Volt High
Bus Short Circuit
PV ISO Under Fault
PV Input Short Circuit
Bypass Relay Fault
INV Curr Over
INV DC Over
Ambient Over Temp
