BMS PARAM
CHAR VOLT : 50V
CHARGE : 60A
DISCHARGE : 10A
GRID DATA
VOLT : 239.8V
CURR : 0.00A
FREQ : 50.12Hz
INV DATA
VOLT : 50.0V
CURR : 0.00A
FREQ : 0.00Hz
BACKUP DATA
VOLT : 237.3V
CURR : 0.00A
POWER
INV : W
GRID : W
LOAD : W
POWER
PV : W
BACKUP : W
BAT : W
Battery Charging Voltage
Battery Charging Current
Battery Discharging
Current
Mains Voltage
Mains Current
Mains Frequency
Inverter Voltage
Inverter Current
Inverter Frequency
Backup Output Voltage
Backup Output Current
Inverter Total Power
Grid Total Power
Load Total Power
PV Generation Power
Backup Output Power
Total Power Supplied
from battery
