4. Operation

4.1 Check before Operation
Please check before Operation according to the following.
• Inverter is installed correctly and steady.
• Reasonable cable layout to meet customer requirements.
• Make sure the grounding is reliable.
• Make sure the ground wire is properly connected, firm and reliable.
• Double check the battery breaker is OFF.
• Make sure the cables are properly connected, firm and reliable.
• Ensure there is plenty of space around the inverter charger and the area is clean and tidy.
4.2 Power ON Test
Make sure the battery voltage is within the permissible range before turning
ON the breaker.
Note: there are three ways the inverter / charger can work
1. Default (test mode)
2. Fitted with Remote P/n: INVCHRD-BT.
3. Without remote or INTELLI-Grid connected.
Default Test Mode
Please follow the following instruction step by step.
• Step 1: Turn on the circuit breaker between the battery and the inverter.
• Step 2: Press the On/Off button to turn on the inverter entering into self diagnostic.
• Step 3: Press the On/Off button again to turn on the inverter.
• Step 4: Observe the LED light to make sure the inverter is running normally.
(refer toTable 2-2 LED directive function)
Power OFF
After the inverter power is turned OFF, there is still residual power and heat in the
chassis, which may lead to electric shock.
- Method 1:Press the On/Off button about 2secs to turn off the output of inverter. Afterwards,
you can press and hold the On/Off for 5secs, after hearing consecutive beep, you can
permanently shut down the inverter.
- Method 2: Press and hold the On/Off for 5secs, after hearing consecutive beep, you can
permanently shut down the inverter straight away.
Remote connected (P/n: INVCHRD-BT)
STEP 1: Turn on the circuit breaker between the battery and inverter.
STEP 2: Turn on the switch on the Remote (P/n: INVCHRD-BT). The inverter should now be working.
STEP 3: Turn the switch off to turn the inverter off.
Inverter Charger Previously used with Remote or INTELLI-Grid system
with no remote connected
STEP 1: Wire in with a latching switch to the remote connections inside the wiring compartment.
STEP 2: Turn on the switch, this will turn the inverter on.
STEP 3: Turn the switch off to turn the inverter off.
