The selection between different AVR devices must be done both in AVR Studio and on
the pod card. In AVR Studio, choose the device you want to emulate in the Device menu
in Emulator Options. On the pod card, make sure to use the appropriate probe cable (20
pins for 20 pin device and so on) and connect your application to the connector labeled
with the correct part number. Please note that it may damage your AT90ICEPRO if you
plug the probe cable into the wrong connector.
To use AT90S2323 ar AT90S2343, the jumpers on the connectors labeled PB3 and
PB4 must be set. Table 3-1 below shows how to set these jumpers.
Table 3-1. Jumper Settings when Selecting between AT90S2323 and AT90S2343
Device
AT90S2323
AT90S2343 with external clock
AT90S2343 with internal clock
For other devices these jumpers are not used.
To use AT90S2333, AT90S4433, AT90S4434 or AT90S8535, the 10 lead cable on the
pod must be mounted. Table 3-2 below shows where to connect this cable.
Table 3-2. Connections of 10-lead cable
Device
AT90S2333 or AT90S4433
AT90S4434 or AT90S8535
For other devices this cable is not used.
Select Between
Different AVR Devices
10-lead cable
ADC and ADC28
ADC and ADC40
Section 3
PB3 PB4
OFF OFF
OFF ON
ON ON
3-1
