Preparing the AVR AT90ICEPRO
Complete the following procedure in order to start using the AVR ICE.
Before connecting the probe cable to the user application:
Connect the pod card to the AVR ICE unit with the pod cable.
Connect the appropriate probe to the pod.
Connect the RS-232 cable between the AVR ICE unit and an available serial port on
the host PC.
Connect power supply (9 - 15 V
Turn the power on and check that the red LED marked "POWER" is lit.
After a short time (≤10 sec.), the green LED marked "READY" will be lit and the AVR
ICEPRO system is ready.
Turn off the power.
Plug the probe into the application, paying attention to connect it correctly. If it is not
connected correctly, the AVR AT90ICEPRO system may be damaged. The colored wire
of the probe cable indicates pin 1 of the AVR device.
When the probe is correctly connected to the application, check the jumper marked
"EXT. POWER" on the probe circuit board. If the application is powered from the AVR
ICE unit, the jumper must be mounted. If the application is going to use its own power
supply, the jumper must be removed.
Make sure that all other jumpers and switches (clock, timer, analog comparator and
device) are set according to your application. Details on these jumper settings are
located in Section 4.
When all jumpers are set correctly, turn on the power. When the green LED is lit, the
AVR AT90ICEPRO system is ready for use. Start AVR Studio, and begin your AVR
emulation session.
System for Use
) to the AVR ICE unit.
