Atmel AT91CAP9 User Manual

Features
•
500,000 Gates/250,000 Gates Metal Programmable Logic (through 5 Metal Layers) for
AT91CAP9S500A/AT91CAP9S250A Respectively
•
Ten 512 x 36-bit Dual Port RAMs
•
Eight 512 x 72-bit Single Port RAMs
•
High Connectivity for Up to Three AHB Masters and Four AHB Slaves
•
Up to Seven AIC Interrupt Inputs
•
Up to Four DMA Hardware Handshake Interfaces
•
Delay Lines for Double Data Rate Interface
•
UTMI+ Full Connection
•
Up to 77 Dedicated I/Os
1. Description
®
The Atmel AT91 Customizable Microcontroller Processor (AT91CAP) concept allows
customization of ARM7
digital logic into a Metal Programmable Block (MPBlock). The AT91CAP is separated
into two different areas:
1. AT91CAP hard part: A fixed area containing the ARM
system, the internal memories and several peripherals described in the
AT91CAP datasheet.
2. MPBlock part: Metal Programmable area dedicated to customization and
using only the metal levels of the technology.
T h e U s e r G u i d e s h o w s t h e c a p a b i l i t i e s f o r c u s t o m i z a t i o n o f t h e
AT91CAP9S500A/AT91CAP9S250A based on a concrete example.
The customization example includes the following objects:
• An AHB2APB Bridge creating a dedicated APB bus inside the MPBlock
• An AHB Peripheral DMA controller
• An APB Debug Unit (UART) connected to the Peripheral DMA Controller
• An Internal RAM Controller using the dedicated MPBlock RAM blocks
The User Guide first describes the AT91CAP9S500A/AT91CAP9S250A database in
terms of directories and logical design structure. It then guides the user through the
complete AT91CAP9S500A/AT91CAP9S250A customization flow using the given
example.
™ ™
or ARM9 platforms by adding specific peripherals and/or
®
processor, the ARM
Customizable
Microcontroller
Processor
AT91CAP9
MPBlock
User Guide
Summary
NOTE: This is a summary document.
The complete document is available
under NDA. For more information,
please contact your local Atmel sales
office.
6324AS–CAP–21-May-07
