8. MISC. COMPONENTS

8.1 TRANSITIONS TO EPS, EPSA, EPS1, EPS2 AND
EPS4 WITH FLANGED CONNECTIONS
This transition section is used when connecting EPSC to
EPS, EPSA, EPS, EPS2 and EPS4 chimneys with flanged

connections.

The transition can also be used when connecting the EPSC
to a TDF inline power venter.
The connection to the power venter is customized for the
appropriate diameter.

8.2 OTHER TRANSITIONS

ENERVEX supplies other types of custom-made transitions.
Shown here is a step-transition from a standard 1/2" flanged
vent to a larger 1/2" flanged vent or other object.
