3100153 RSHT009 - 016 2012-11-15
RSHT009-016
READ AND SAVE THESE INSTRUCTIONS!
Product information
Mechanical installation
Electrical installation
Start up and configuration
Maintenance and troubleshooting
Job name: _________________________________
Installer: __________________________________
Installation date: ___________________________
Distributor contact information:
ENERVEX Inc. • T: 800.255.2923
info@enervex.com • www.enervex.com
Installation and operation manual
Volko Supply
www.chimneyfansource.com
800 685 8263
Chapters 1 + 2
Chapter 3
Chapter 4
Chapter 5
Chapter 6
USA
CAN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RSHT009-016 and is the answer not in the manual?

Questions and answers

Summary of Contents for ENERVEX RSHT009-016

  • Page 1 Chapters 1 + 2 Mechanical installation Chapter 3 Electrical installation Chapter 4 Start up and configuration Chapter 5 Maintenance and troubleshooting Chapter 6 Job name: _________________________________ Installer: __________________________________ Installation date: ___________________________ Distributor contact information: ENERVEX Inc. • T: 800.255.2923 info@enervex.com • www.enervex.com...
  • Page 2: Table Of Contents

    3. Installation work and electrical wiring must be done by a quali- documentation. System design documentation is available from fied person(s) in accordance with applicable codes and standards. ENERVEX. 4. Follow the appliance manufacturer’s guidelines and safety Accessories and variable frequency drives are not covered by this standards such as those published by the National Fire Protection manual.
  • Page 3: Function

    (not including dismantling and installation, freight, etc.) during the first 10-years following the date of installation. Complete warranty conditions are available at www.enervex.com or request a copy at: info@enervex.com or at tel.: 1-800.255.2923.
  • Page 4: Dimensions And Capacities

    3100153 RSHT009 - 016 2012-11-15 2. Specifications 2.1 Dimensions and capacities Model RS009 RS012 RS014 RS016 Discharge Horizontal Fan Type Axial Vane Motor Type Totally enclosed, Variable speed, Class F Voltage V AC 1x120 1780 1780 1780 1730 0.0 Ps 1430 Amperage Amps...
  • Page 5: Planning Ahead

    3100153 RSHT009 - 016 2012-11-15 2.2 Planning ahead 1. Observe proper combustion air requirements. 2. Provide a firm support system for the chimney fan. 3. Determine the type of system involved. 4. Observe proper safety measures are taken to assure safe use of the wood burning appliances. Combustion air requirements Provisions for combustion air must be in accordance with applicable local codes.
  • Page 6: Transport Safety Device

    3100153 RSHT009 - 016 2012-11-15 3. Mechanical installation 3.1 Transport safety device Remove the transport safety device from the vane and make sure that the vane can revolve without hindrance. 3.2 Prior to operation To open the fan: Remove the two nuts Too secure the fan in open position Always mount the fan in vertical at the front and pull out the lock pin at...
  • Page 7: Single Fan On Brick Chimney

    3100153 RSHT009 - 016 2012-11-15 Step 2: Preparation of exodraft fan Locate the installation brackets in the slots going through the fan base part, using the bolts and nuts supplied to secure the brackets. If the flue diameter is larger than the chimney fan inlet, the bracket can be installed underneath the base part.
  • Page 8: Multiple Fans On Steel Chimney

    3100153 RSHT009 - 016 2012-11-15 Step 3: Attaching the fan The chimney fan is now ready for installation on the top of the chim- ney. Place fiber mat with the aluminum foil facing upwards on the top of the chimney, and place the fan on top of the mat. High temperature silicone can be applied on the side of the mat, but is not required.
  • Page 9: General

    3100153 RSHT009 - 016 2012-11-15 4. Electrical installation 4.1 General DANGER Turn off electrical power before servicing. Contact with live electric components can cause shock or death. All electrical wiring must be in accordance with requirements of authority having jurisdiction or, in absence of such re- quirements, with National Electrical Code NFPA 70 —...
  • Page 10: Connection And Wiring Diagram For Two Fans With Fan Speed Control

    3100153 RSHT009 - 016 2012-11-15 4.3 Connection and wiring diagram for two fans with fan speed control The diagrams below show the wiring of two chimney fans and how they are connected to the fan speed control. Chimney fans MOTOR MOTOR Junction box Junction box...
  • Page 11: System Testing

    3100153 RSHT009 - 016 2012-11-15 5. Start-up and configuration 5.1 System testing Before any adjustments are made to the system, follow these procedures: Turn the chimney fan ON and make sure that it is operating. Increase and decrease the speed of the fan by adjusting the fan speed control to make sure it is operating properly.
  • Page 12: Operating Pizza Oven

    3100153 RSHT009 - 016 2012-11-15 5.5 Operating pizza oven Prior to starting a fire, set the fan at high/full speed and start the fire following the oven manufacturer’s instructions or, in the absence of such instructions, normal instructions for burning a fire in a fireplace or stove. After the fire catches on, after 3-5 minutes, reduce the speed of the chimney fan to a level where it safely removes the flue gases and a perfect flame can be maintained.
  • Page 13: Replacing Wheel And Motor

    3100153 RSHT009 - 016 2012-11-15 6.2 Replacing wheel and motor Replace wheel A. Loosen the insert hex screw B. Use the 1/4” screw as a tap C. Pull the vane plug out D. Unscrew and remove the 1/4” bolt at the end of the vane pipe axle E.
  • Page 14: Chimney Cleaning Intervals

    3100153 RSHT009 - 016 2012-11-15 6.3 Chimney cleaning intervals It is extremely important to keep the chimney flue clean from creosote and deposits. Creosote is the major cause of chimney fires. Cleaning intervals depend on the use of the appliance. The more the appli- ance is used, the more often the chimney flue needs cleaning.
  • Page 15: Notes

    3100153 RSHT009 - 016 2012-11-15 Notes...
  • Page 16 Distributor in USA & Canada P: 770.587.3238 ENERVEX Inc. F: 770.587.4731 1685 Bluegrass Lake Parkway T: 800.255.2923 Alpharetta info@enervex.com GA 30004 www.enervex.com Volko Supply www.chimneyfansource.com 800 685 8263 www.exodraft.com...
