- Page 1 ENERVEX RS CHIMNEY FAN FOR GAS & OIL APPLICATIONS 3000270 05.16 Installation & Operating Manual READ AND SAVE THESE INSTRUCTIONS! ETL514733 ENERVEX Inc. P: 770.587.3238 1685 Bluegrass Lakes F: 770.587.4731 Parkway T: 800.255.2923 Alpharetta, GA 30004 info@enervex.com www.enervex.com...
- Page 2 3000270 05.16 ETL514733 This symbol shows that ENERVEX RS Chimney Fans for solid fuel applications are listed under ETL File no. 514733. Symbol Legend The following terms are used throughout this manual to bring TO REDUCE THE RISK OF FIRE,...
-
Page 3: Table Of Contents
3000270 05.16 Content 1. GENERAL INFORMATION 1.1 Function ....................4 1.2 Shipping ....................4 1.3 Warranty ....................4 2. SPECIFICATIONS AND DIMENSIONS 2.1 Dimensions and Capacities ...............5 2.2 Planning Ahead .................6 3. MECHANICAL INSTALLATION 3.1 Transport Safety Device ..............7 3.2 Single Fan on Steel Chimney .............7 3.3 Single Fan on Brick Chimney .............8 3.4 Multiple Fans on Steel Chimney ............9 3.5 Multiple Fans on Brick Chimney - Oversized Flue .......9... -
Page 4: General Information
The capacitor is located INSIDE the junction box. Please do not discard. 1.3 WARRANTY ENERVEX products are warranted for a period of two (2) years following the date of invoice. Replacement or repair will be at ENERVEX’s discretion, provided factory inspection shows a defect in material or workmanship. -
Page 5: Dimensions And Capacities
3000270 05.16 2. SPECIFICATIONS 2.1 DIMENSIONS & CAPACITIES Model RS 009 RS 012 RS 014 RS 016 Discharge Horizontal Fan Type Axial Vane Motor Type Totally enclosed, Variable speed, Class H Voltage 1x120V @ 60 Hz Amperage Amps 1600 @0.0 Ps... -
Page 6: Planning Ahead
3000270 05.16 2.2 PLANNING AHEAD Observe proper combustion air requirements. System type Direct connect oil or gas appliances (no draft hood) normally Provide a firm support system for the chimney fan. do not require any mechanical draft adjustment. However, Determine the type of system involved. if there are long horizontal breechings and far between Observe proper safety measures are taken the appliances, it is a good idea to install mechanical vent... -
Page 7: Mechanical Installation
3000270 05.16 3. MECHANICAL INSTALLATION 3.1 TRANSPORT SAFETY DEVICE If a transport safety device is present, remove it from the vane and make sure that the vane can revolve without hindrance. RS 14/16: Before mounting, the transport safety device on the hinges must be removed. -
Page 8: Single Fan On Brick Chimney
3000270 05.16 3.3 SINGLE FAN ON BRICK CHIMNEY Step 1: Prepare fan location The installation procedure is the same whether the flue is round or square. If a clay tile flue liner is installed, it might stick up a few inches. Cut it back so it is flush with or no more than 1/2 inch above the chimney crown. -
Page 9: Multiple Fans On Steel Chimney
3000270 05.16 3.4 MULTIPLE FANS ON STEEL CHIMNEY If two or more chimney fans are required to create sufficient draft, installation procedures are the same as for single fan installation on a steel chimney. The only difference is that the fans are sitting next to each other on the top of the chimney. -
Page 10: Wall Mounting Of Chimney Fan
PDS Installation Manual if this control is used. For more information on alternative safety systems, please contact ENERVEX, Inc. The figure shows the location of the probe for the PDS. Location is important to make sure there is enough pressure or draft available or the switch to work. - Page 11 3000270 05.16 The combustion air inlet and flue gas outlet of a direct vent appliance or the flue gas outlet of an appliance other than a direct vent appliance shall terminate at least 1 ft (0.3 m) from the soffit of the roof of the structure and at least 3 ft (0.9 m) from an inside corner of an L-shaped structure.
-
Page 12: Electrical Installation
3000270 05.16 4. ELECTRICAL INSTALLATION 4.1 GENERAL DANGER Turn off electrical power before servicing. Contact with live components can cause shock or death. All electrical wiring must be in compliance with the local codes or in their absence, with the National Electric Code, NFPA 70 —... -
Page 13: Wiring For Two Fans With Fsc
3000270 05.16 4.3 WIRING DIAGRAM FOR TWO FANS WITH FAN SPEED CONTROL The diagrams at right show the wiring of two chimney fans PROVEN DRAFT SWITCH and how they are connected to the fan speed control. 24 VAC MOTOR MOTOR 24V GAS VALVE 120/1/60 WEATHERPROOF... -
Page 14: Startup And Configuration
3000270 05.16 5. STARTUP AND CONFIGURATION 5.1 SYSTEM TESTING Before any adjustments are made to the system, follow these procedures: 1. Turn the chimney fan ON and make sure that it is operating. Increase and decrease the speed of the fan by adjusting the fan speed control to make sure it is operating properly. -
Page 15: Maintenance And Troubleshooting
3000270 05.16 6. MAINTENANCE AND TROUBLESHOOTING 6.1 PRIOR TO CLEANING Remove butterfly nut or screw from each hinge prior to cleaning. Remove Butterfly Nut or Screw from each Hinge 6.2 CARE AND CLEANING The Chimney Fan System is designed for prolonged use. The fan should be inspected at least one a year when the chimney is inspected. -
Page 16: Troubleshooting
3000270 05.16 6.4 TROUBLESHOOTING Observation Problem Solution – The circuit breaker may be off – Check the circuit breaker There is no power going to the fan – Fan speed control is off – Turn fan speed control on – Bad electrical connections –... - Page 17 3000270 05.16 Notes...
- Page 18 ENERVEX Inc. P: 770.587.3238 1685 Bluegrass Lakes F: 770.587.4731 Parkway T: 800.255.2923 Alpharetta, GA 30004 info@enervex.com www.enervex.com...
