- Page 1 EC18000VE/D EC22000VE/A EC22000VE/B GENERATORS GENERATORS AN AMERICAN COMPANY INSTALLATION AND OPERATORS MANUAL www.wincogen.com...
-
Page 2: Table Of Contents
GASOLINE FUEL SUPPLY LUBRICATION COPY YOUR MODEL AND SERIAL NUMBER HERE No other WINCO generator has the same serial number as OIL RECOMMENDATIONS yours. If you should ever need to contact us concerning this OIL ALERT SYSTEM unit, it will help us to respond to your needs faster. -
Page 3: Safety Information
SAFETY INFORMATION D. Keep a fire extinguisher nearby and know its proper This engine generator set has been designed and use. Fire extinguishers rated ABC by NFPA are manufactured to allow safe, reliable performance. Poor appropriate. maintenance, improper or careless use can result in E. -
Page 4: Specifications
SPECIFICATIONS EC18000VE EC22000VE Starting Watts 18,000 Starting Watts 22,000 22,000 22,000 22,000 Running Watts 15,000 Running Watts 19,000 19,000 19,000 19,000 Volts 120/240 Volts 120/240 120/208 120/240 277/480 Phase 62.5 Phase Single Three Three Three Amps 120/240V 125/62.5 Amps CB Size 60 Amp CB Size 80 Amp... -
Page 5: Introduction
INTRODUCTION TESTING POLICY utilized from C reduces the power available from both A and B and vice versa. The EC22000 utilizes the same format Before any generator is shipped from the factory, it is fully with A and B being 9500 Watts and C being 19,000 Watts. checked for performance. -
Page 6: Preparing The Unit
If any damage is noted, it is always easiest to and you will be left with varnish residue. The varnish refuse the shipment and let WINCO take care of the like substance will clog the carburetor and will not burn freight claim. -
Page 7: Oil Recommendations
Outdoor temperatures determine the proper oil viscosity for These electric start engines are NEGATIVE GROUND. Use the engines. Winco recommends our 5W-30 fully synthetic extreme caution when connecting the battery. Connect oil to give you excellent protection in cold temperatures the NEGATIVE battery terminal to GROUND. -
Page 8: Initial Start Up
INITIAL START UP The throttle control on these generators is preset and STOPPING AND STORING locked to operate at 3600 RPM (nominal) with no load 1. Move the key to the “OFF” position. speed set at 3690 RPM. Only a trained service technician 2. - Page 9 under varying loads: LOAD vs. OUTPUT Generator Speed Frequency Voltage Load (RPM) (Hz) None 3690 61.5 125V Half 3600 60.0 120V Full 3510 58.5 115V The speed of the engine was carefully adjusted at the factory so that the generator produces the proper voltage and frequency.
-
Page 10: Connecting The Loads
CONNECTING THE LOADS GROUNDING Failure to properly limit and balance the load applied to the generator will cause the generator to produce low voltage and may damage the engine generator set. It may All units must be grounded. Different installations will also cause severe damage to the loads connected to the require different grounding requirements. -
Page 11: Engine Care
E. To loosen debris, gently tap Outdoor temperatures determine the proper oil viscosity for the air filter on a hard surface. the engines. Winco recommends our 5W-30 fully synthetic If the air filter is excessively oil to give you excellent protection in cold temperatures dirty replace with a new filter. -
Page 12: Generator Care
GENERATOR CARE H. Install the air filter and secure the retainer and nut. I. Install and secure the cover. Proper care and maintenance of the generator is necessary SPARK PLUG to ensure a long trouble free life. Replace annually or every 300 hours of operation. Always EXERCISING THE GENERATOR replace with the same spark plug that came in the engine and check gap before installing. -
Page 13: Troubleshooting
TROUBLESHOOTING Problem Possible Causes Won’t start Low oil level Fouled spark plug Out of fuel Start switch in OFF position Fuel Valve turned off Plugged fuel filter Blown fuse in key switch Voltage too low Engine speed is too low Generator overloaded Defective stator Defective rotor (field) -
Page 14: Receptacle Wiring Diagram
RECEPTACLE WIRING DIAGRAM EC18000VE 60706-231/H... -
Page 15: Distribution Wiring Diagram
DISTRIBUTION WIRING DIAGRAM EC22000VE 120/240 SINGLE PHASE 120/208 & 120/240 THREE PHASE 277/480 THREE PHASE 60706-231/H... -
Page 16: Ec22000Ve Ac Wiring
EC22000VE AC WIRING 1-PHASE 3-PHASE 120/240 120/208 LOW WYE 3-PHASE 3-PHASE 120/240 DELTA 277/480 HIGH WYE 60706-231/H... -
Page 17: Limited Warranty
Air cooled units purchased for stock have 1 year to be sold. The warranty to the original retail customer commences on the date of sale of the product to them. All liquid cooled units have 180 days from the Winco invoice to submit a start up date. - Page 18 Standby use is defined as an application where utility power is present -and- the generator set is used as emergency backup during utility power outages. WINCO reserves the right to change or improve it’s products without incurring any obligations to make such changes or improvements on products purchased previously.
-
Page 19: Ca Evap Emission Control
22. Travel time or service calls unless specifically authorized by Winco, Inc. in writing. GENERAL INFORMATION The WINCO, Inc. Service Department is open from 7:30 AM to 4:30 PM Central Standard time. It is located at 225 South Cordova Ave., Le Center, MN, 56057-1805. Phone Numbers: Service Department - 507-357-6831 FAX Line - 507-357-4857. - Page 20 GENERATORS AN AMERICAN COMPANY 225 S. CORDOVA AVE • LE CENTER, MN 56057 Sales: 507-357-6821• sales@wincogen.com Service: 507-357-6831 • service@wincogen.com www.wincogen.com 60706-231/H...
