Instructions – Parts List
Wall Mount Air–Assisted
Packages
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441
Copyright 2002, Graco Inc. is registered to I.S. EN ISO 9001
Parts
Model 232204 Shown
308757F
7826B
Advertisement
Related Manuals for Graco President 232204
Summary of Contents for Graco President 232204
- Page 1 Wall Mount Air–Assisted Packages 308757F Important Safety Instructions Read all warnings and instructions in this manual. Save these instructions. 7826B Model 232204 Shown GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441 Copyright 2002, Graco Inc. is registered to I.S. EN ISO 9001...
-
Page 2: Table Of Contents
........Graco Standard Warranty ..... . - Page 3 D This equipment is for professional use only. D Read all instruction manuals, tags, and labels before operating the equipment. D Use the equipment only for its intended purpose. If you are uncertain about usage, call your Graco distributor. D Do not alter or modify this equipment. Use only genuine Graco parts and accessories.
- Page 4 Permanently coupled hoses cannot be repaired; replace the entire hose. D Use only Graco approved hoses. Do not remove any spring guard that is used to help protect the hose from rupture caused by kinks or bends near the couplings.
- Page 5 WARNING FIRE AND EXPLOSION HAZARD Improper grounding, poor ventilation, open flames, or sparks can cause a hazardous condition and result in a fire or explosion and serious injury. D Ground the equipment and the object being sprayed. Refer to Grounding on page 10. D If there is any static sparking or you feel an electric shock while using this equipment, stop spray- ing immediately.
- Page 6 Notes 308757...
- Page 7 Use a coalescing air filter in the main air supply line. NOTE: Always use Genuine Graco Parts and Acces- sories, available from your Graco distributor. Refer to Product Data Sheet 305899. If you supply your own...
- Page 8 Installation D The twin hose (101) includes a gun air supply Supplied Components hose (101a) and a gun fluid supply hose (101b). Refer to Fig. 1. The fluid whip hose (103) allows greater gun maneuverability. WARNING D The gun filter/swivel (104) provides a final filtering of fluid before it enters the gun, and allows greater A red-handled bleed-type master air valve (E) and gun maneuverability.
- Page 9 Installation Fluid Regulator Detail SUPPLIED COMPONENTS COMPONENTS YOU MUST SUPPLY Wall Bracket Electrically Conductive Air Supply Hose Pump Bleed-Type Master Air Valve Fluid Filter (includes fluid drain valve F) (for accessories) Ground Wire (required; see page 10 Air Line Filter for installation instructions) Air Line Moisture Trap and Drain Valve Suction Hose...
- Page 10 Installation Grounding 2. Air and fluid hoses: use only electrically conductive hoses. WARNING 3. Air compressor: follow manufacturer’s recommen- FIRE AND EXPLOSION HAZARD dations. Before operating the pump, ground the system as explained below. Also read the section FIRE AND EXPLOSION HAZARD on page 5.
- Page 11 Pressure Relief Procedure Before starting, fill the packing nut (M) 1/3 full with whenever you: Graco Throat Seal Liquid (TSL) or compatible solvent. D are instructed to relieve the pressure, See Fig. 3. D stop spraying,...
- Page 12 Notes 308757...
- Page 13 Operation Prime the Pump 10. Cycle the pump slowly until all air is pushed out and the pump and hoses are fully primed. 1. See Fig. 3. Remove the tip guard and spray tip from the gun (106). Refer to the gun manual. 11.
- Page 14 Operation Adjust the Spray Pattern 3. To adjust the spray pattern, follow the instructions in your gun manual, supplied. 1. Start the pump. Use the pump air regulator (G) to adjust the pump speed and fluid pressure until the 4. With the pump and lines primed, and with ade- spray is completely atomized.
- Page 15 Operation Fluid Regulator Detail Fluid Filter (includes fluid drain valve F) Electrically Conductive Air Supply Hose Suction Hose Bleed-Type Master Air Valve Suction Tube (for accessories) Bung Adapter (carbon steel models only) Red-Handled Bleed-Type Master 101 Electrically Conductive Gun Air/Fluid Hose Air Valve (required, for pump) (includes items 101a and 101b) Fluid Drain Valve...
- Page 16 Notes 308757...
- Page 17 Maintenance Preventive Maintenance Schedule Flush with a fluid that is compatible with the fluid you are pumping and with the wetted parts in your system. The operating conditions of your particular system Check with your fluid manufacturer or supplier for determine how often maintenance is required.
- Page 18 Parts Model 232204 Shown † Model 233079 Only: Nipple (Ref. 102 cst) is assembled to If you order a new twin air/fluid hose (101), cut the coupling off elbow (Ref. 19). A spare nipple is provided for users who one end of the red air hose so that the hose is 2 in. (50 mm) want to add a second gun to the outlet filter (Ref.
- Page 19 Parts Part No. 232204, 30:1 President, carbon steel (shown) Part No. 232205, 30:1 President, carbon steel, without hose and gun Part No. 232215, 30:1 President, stainless steel Part No. 232216, 30:1 President, stainless steel, without hose and gun Part No. 232226, 23:1 Monark, carbon steel Part No.
- Page 20 Parts NOTE: Part numbers vary by package. To find the part number used in your package, read down the chart to find the desired ref. no., then read left to right to find the part number for your package. Packages Ref.
- Page 21 Parts NOTE: Part numbers vary by package. To find the part number used in your package, read down the chart to find the desired ref. no., then read left to right to find the part number for your package. Packages Ref.
- Page 22 Hose and Gun Parts Part No. 232204, 30:1 President, carbon steel (shown) Part No. 232215, 30:1 President, stainless steel Part No. 232226, 23:1 Monark, carbon steel Part No. 232237, 23:1 Monark, stainless steel Part No. 232244, 15:1 President, carbon steel Part No.
- Page 23 Fluid Regulator Parts Part No. 232251, 15:1 Monark, stainless steel Part No. 232252, 15:1 Monark, stainless steel, without hose and gun Part No. 232255, 15:1 Monark, carbon steel Part No. 232256, 15:1 Monark, carbon steel, without hose and gun NOTE: The following part numbers apply only to packages supplied with a fluid regulator. Part numbers vary by package.
-
Page 24: Technical Data
Technical Data Category Data Maximum fluid Part Nos. 232204, 232205, 232215, 232216, 233079: 3000 psi (21 MPa, 210 bar) working pressure Part Nos. 232226, 232227, 232237, 232238: 2300 psi (16 MPa, 160 bar) Part Nos. 232244, 232245, 232251, 232252, 232255, 232256: 1500 psi (10 MPa, 100 bar) Maximum air input All Part Nos.: 100 psi (0.7 MPa, 7 bar) - Page 25 Technical Data Performance Charts To find Fluid Outlet Pressure (psi/MPa/bar) at a specific fluid flow To find Pump Air Consumption (m#/min. or scfm) at a specific fluid (lpm/gpm) and operating air pressure (psi/MPa/bar): flow (lpm/gpm) and air pressure (psi/MPa/bar): 1. Locate desired flow along bottom of chart. 1.
-
Page 26: Dimensions
Dimensions Model 232204 Shown Mount the pump assembly so the top of the bracket is 4 to 5 ft (1.2 to 1.5 m) above the floor. 7826B Pump Model 232204/205/233079 32 in. (813 mm) 17 in. (432 mm) 36 in. (914 mm) President 30:1 Carbon Steel 232215/216 President 30:1... -
Page 27: Mounting Hole Layout
Mounting Hole Layout Check that the bracket is level before bolting it to the wall. Mount the pump assembly so the top of the bracket (1) is 4 to 5 ft (1.2 to 1.5 m) above the floor. 1.0 in. (25.4 mm) 5.0 in. -
Page 28: Graco Standard Warranty
Graco distributor to the original purchaser for use. With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
