Instructions – Parts List
Pail Mount
Airless Packages
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
See page 2 for table of contents.
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441
Copyright 1999, Graco Inc. is registered to I.S. EN ISO 9001
308765F
Model 232437 Shown
8109C
0359
II 1/2 G T3
ITS03ATEX11251
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Graco 232437
Summary of Contents for Graco 232437
- Page 1 Save these instructions. See page 2 for table of contents. GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441 Copyright 1999, Graco Inc. is registered to I.S. EN ISO 9001 308765F Model 232437 Shown 8109C 0359 II 1/2 G T3 ITS03ATEX11251...
-
Page 2: Table Of Contents
Series Pump Model 232433 Monarkr, carbon steel, with hose and gun, without agitator 232434 Monarkr, carbon steel, without agitator, hose, and gun 232437 Monarkr, carbon steel, with agitator, hose, and gun 232445 Monarkr, stainless steel, with hose and gun, without agitator 232446... -
Page 3: Warning Symbol
Warning Symbol WARNING This symbol alerts you to the possibility of serious injury or death if you do not follow the instructions. EQUIPMENT MISUSE HAZARD Equipment misuse can cause the equipment to rupture or malfunction and result in serious injury. INSTRUCTIONS D This equipment is for professional use only. - Page 4 SKIN INJECTION HAZARD Spray from the gun, hose leaks, or ruptured components can inject fluid into your body and cause extremely serious injury, including the need for amputation. Fluid splashed in the eyes or on the skin can also cause serious injury. D Fluid injected into the skin might look like just a cut, but it is a serious injury.
- Page 5 FIRE AND EXPLOSION HAZARD Improper grounding, poor ventilation, open flames or sparks can cause a hazardous condition and result in a fire or explosion and serious injury. D Ground the equipment and the object being sprayed. Refer to Grounding on page 7. D If there is any static sparking or you feel an electric shock while using this equipment, stop spray- ing immediately.
-
Page 6: General Information
D 308765, Pail Mount Airless Packages D 307619, Monark 23:1 CST and SST Pumps D 307043, Monark Air Motor D 308686, Air Regulator Kit D 307273, Fluid Filter D 306565, Agitator (Models 232437 and 232449 only) D 311254, Airless Spray Gun 308765 Setup... - Page 7 (18) into the slot in lug (Z) and tighten the locknut securely. Connect the other end of the wire to a true earth ground. 2. Agitator (Models 232437 and 232449 only): one end of the agitator ground wire (40, supplied) is fastened to the agitator motor with a screw. Insert the other end of the ground wire into the slot in lug (Z).
-
Page 8: Supplied Components
(see the WARNING at left). D The agitator (39), included on Models 232437 and 232449 only, keeps the fluid in suspension. D The airless spray gun (106) dispenses the fluid. - Page 9 Model 232437 Shown SUPPLIED COMPONENTS 5 Gallon (19 liter) Pail Cover Pump Fluid Filter (includes fluid drain valve F) Air Relief Valve Pump Ground Wire (required; see page 7 for installation instructions) 5 Gallon (19 liter) Pail Agitator Agitator Ground Wire...
-
Page 10: Pressure Relief Procedure
Pressure Relief Procedure WARNING SKIN INJECTION HAZARD The system pressure must be manually relieved to prevent the system from starting or spraying accidentally. Fluid under high pressure can be injected through the skin and cause serious injury. To reduce the risk of an injury from injection, splashing fluid, or moving parts, follow the Pressure Relief Procedure whenever you:... -
Page 11: Prime The Pump
Close the drain valve when all air is eliminated. Operation Agitator Operation (Models 232437 and 232449) 1. Slowly open the control valve (J) to start the agitator (39). See Fig. 3. - Page 12 Adjust the Spray Pattern 1. Start the pump. Use the pump air regulator (G) to adjust the pump speed and fluid pressure until the spray is completely atomized. Use the lowest pressure necessary to get the desired results. Higher pressure may not improve the spray pattern and will cause premature tip and pump wear.
- Page 13 Model 232437 Shown 5 Gallon (19 liter) Pail Cover Pump Fluid Filter (includes fluid drain valve F) 5 Gallon (19 liter) Pail Screw Knobs Agitator Agitator Air Supply Tube 101 Electrically Conductive Fluid Hose 103 Fluid Whip Hose 104 Gun Filter/Swivel...
-
Page 14: Preventive Maintenance Schedule
Preventive Maintenance Schedule The operating conditions of your particular system determine how often maintenance is required. Estab- lish a preventive maintenance schedule by recording when and what kind of maintenance is needed, and then determine a regular schedule for checking your system. -
Page 15: Parts
Part No. 232434, Series A, 23:1 Monark, cst, without agitator, hose, and gun Part No. 232437, Series A, 23:1 Monark, cst, with agitator, hose, and gun (shown) Part No. 232445, Series A, 23:1 Monark, sst, without agitator, with hose and gun Part No. - Page 16 Part No. 232434, Series A, 23:1 Monark, cst, without agitator, hose, and gun Part No. 232437, Series A, 23:1 Monark, cst, with agitator, hose, and gun (shown) Part No. 232445, Series A, 23:1 Monark, sst, without agitator, with hose and gun Part No.
- Page 17 Part No. 232437, Series A, 23:1 Monark, carbon steel (shown) 17 (Ref) Parts 40 (Ref) 41 (Ref) 23, 25 7 (Ref) 308765 8107B 8107C...
-
Page 18: Technical Data
Category Maximum fluid working pressure Maximum air input pressure Ratio Maximum operating temperature Wetted parts Air Motor 40 psi (0.28 MPa, 2.8 bar) Monark 73.3 dB(A) (tested in accordance with ISO 9614–2) Air Motor 40 psi (0.28 MPa, 2.8 bar) Monark 87.0 dB(A) To find Fluid Outlet Pressure (psi/MPa/bar) at a specific fluid flow... -
Page 19: Dimensions
Dimensions Model 232437 Shown (hose and gun not shown) 8110A A (height) B (diameter of pail) Weight 32 in. (813 mm) 10.625 in. (270 mm) 47 lb (21 kg) 308765... -
Page 20: Graco Standard Warranty
Graco Standard Warranty Graco warrants all equipment manufactured by Graco and bearing its name to be free from defects in material and workmanship on the date of sale to the original purchaser for use. With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
