- Page 1 ArgentDCP Hardware Reference Manual (Revision 1)
- Page 2 Copyright 2001 Avaya Inc. All rights reserved. Published by Avaya Inc., who reserve the right to make improvements to the products described in this manual and to revise this publication at any time without notice to any person of such changes.
-
Page 3: Table Of Contents
Statutory Restrictions...................7 Further Information and Product Updates ................8 Product Variants........................9 ArgentDCP 16....................9 Current Country Variants................9 Port Labelling........................10 ArgentDCP 16 - Front View ..............10 ArgentDCP 16 - Rear View................10 Port Connections ........................11 Extension Port....................11 DTE Port....................11 DC Power Input Connector................12 Expansion Port...................12 Section 2: Technical Data ..............13... - Page 4 Revision 1...
-
Page 5: Introduction To Argentdcp
Section 1: Introduction to ArgentDCP Section 1: Introduction to ArgentDCP This section contains … About ArgentDCP, page 6 Safety and Homologation Statements, page 7 Further Information and Product Updates, page 8 Product Variants, page 9 Port Labelling, page 10 Port Connections, page 11... -
Page 6: About Argentdcp
This Hardware Reference Manual provides technical information on the ArgentDCP module, including: Approval Statements, Safety Declarations, Port Labelling and Pin-Out Information, Cable Specifications and Technical Specifications. -
Page 7: Safety And Homologation Statements
Please see the associated Declaration of Conformity, these can be found within the Approvals folder. TATUTORY ESTRICTIONS The 2A 24V Lump-in-Line PSU supplied with the ArgentDCP module must only be connected to 50/60Hz AC power sources in the range 100 – 240V. Revision 1... -
Page 8: Further Information And Product Updates
Section 1: Introduction to ArgentDCP FURTHER INFORMATION AND PRODUCT UPDATES Further information, including Product and Reference Manual updates, can be obtained from Avaya Inc. Alchemy Dealers and Distributors, or from the Avaya Inc. Alchemy web site http://www.avaya.co.uk/products/#alchemy Revision 1... -
Page 9: Product Variants
The Alchemy Series ArgentDCP is currently available for the UK and European markets. The power supply used for the ArgentDCP is a Lump-in Line unit, rated at 24V, 2A and has an integral DC power lead but a separate mains lead. -
Page 10: Port Labelling
Section 1: Introduction to ArgentDCP PORT LABELLING This section illustrates the ports on the ArgentDCP module. DCP 16 - F RGENT RONT The following diagram shows the port labelling on the front of the Alchemy Series ArgentDCP 16 module: Unit... -
Page 11: Port Connections
The ArgentDCP 16 has two banks of 8 x RJ45 sockets. The ArgentDCP extension ports are not labelled. This allows users to pursue their own labelling schemes. Each port may be labelled as appropriate. -
Page 12: Dc Power Input Connector
If this problem persists you should call your supplier or maintainer. XPANSION The ArgentDCP 16 has one Expansion port. This is located on the rear of the unit and is labelled as follows: EXPANSION The Expansion port is used to connect the ArgentDCP 16 to any main Argent system unit Expansion socket. -
Page 13: Technical Data
Section 2: Technical Data Section 2: Technical Data This section contains … Port Pin-outs, page 14 Cables, page 17 Port Safety Classification, page 19 Technical Specifications, page 20 Revision 1... -
Page 14: Port Pin-Outs
Section 2: Technical Data PORT PIN-OUTS This section provides technical specifications for the ArgentDCP ports. DTE P OCKET Pin 1 Pin 25 Pin No. Description Signal Direction Transmit Data (TxD) Receive Data (RxD) Request to Send (RTS) Clear to Send(CTS) -
Page 15: Expansion Port (Rj45 Socket)
Section 2: Technical Data (RJ45 S XPANSION OCKET Pin 1 Pin 8 Pin No. Description Signal Direction Receive Data (Rx-B) Receive Data (Rx-A) Sync-B Clock (Clk-B) Clock (Clk-A) Sync-A Transmit Data (Tx-B) Transmit Data (Tx-A) Revision 1... -
Page 16: Extension Port
Section 2: Technical Data XTENSION Pin 1 Pin 8 Pin No. Description Signal Direction Data/Power Data/Power This product is approved for internal use only. If any cables connected to the product leave the building it is the responsibility of the equipment installers to ensure the cables are adequately protected. -
Page 17: Cables
Section 2: Technical Data CABLES This section provides information about the cables that are used with ArgentDCP. DCE C ABLE Part No: CABMANSN02M0PS00 Sales Feature: ARG-TAC 25 Way D-Type Plug with UNC 4-40 locking screws. 9 Way D-Type Socket with UNC 4-40 locking screws. -
Page 18: Expansion Interconnect Cable
Section 2: Technical Data XPANSION NTERCONNECT ABLE Part No: CABTDMSN01M0PP00 Sales Feature: ARG-VIC The RJ45 Plug Shell at each end of the cable is connected to the STP Cable Drain Wire. Shielded RJ45 Plug. Shielded RJ45 Plug. STP (Shielded Twisted Pair) cable – BLUE. 1 metre. -
Page 19: Port Safety Classification
Section 2: Technical Data PORT SAFETY CLASSIFICATION The Alchemy Series ArgentDCP 16 has the following ports: 1 x Expansion port 1 x DTE port 1 x DC Power Input port 16 x Digital ArgentDCP extension ports These ports are classified as follows:... -
Page 20: Technical Specifications
245mm. Environmental 0 to +40°C. 95% relative humidity, non-condensing. Weight ArgentDCP 16 Unit + PSU – 3.30 Kg. Unit only – 3.00 Kg. Power ArgentDCP 16 2.5mm DC inlet socket – GREEN. Rating – 24Vdc, 2A max. Power Adapter is CE Safety Approved. -
Page 21: Fitting/Upgrade Instructions
Section 3: Fitting/Upgrade Instructions Section 3: Fitting/Upgrade Instructions This section contains … Rack Mounting Assembly Instructions, page 22 Revision 1... -
Page 22: Rack Mounting Assembly Instructions
Section 3: Fitting/Upgrade Instructions RACK MOUNTING ASSEMBLY INSTRUCTIONS Revision 1... - Page 23 INDEX ArgentDCP port connections about · 6 DC power input connector · 12 cables · 17 DTE port · 11 port connections · 11 expansion port · 12 port labelling · 10 extension port · 11 port pinouts · 14 port labelling ·...
