Page 1
Avaya IP Office UC110 Module
Installation and Set Up
Telquest Tech Support
Note: The UC110 will only work on KSU's with Release 8.0 and higher.
Power the KSU down
Install the UC110 Module in any slot.
Power the KSU up.
Connect the KSU and your computer to the same LAN.
Do not use the RJ-45 Jack on the front of the UC 110 Module.
The UC110 can be accessed by using the IP Address of the KSU followed by Port Number 7070
Example:
If your KSU is 192.168.1.123 then the UC110 will be found at http://192.168.1.123:7070
The Logon is:
webcontrol
The Password is:
web
Button and LED Info for the UC110 Module, Front View:
DO NOT Connect to this port... DO NOT remove the protective cover...
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Avaya UC110
Summary of Contents for Avaya UC110
- Page 1 Connect the KSU and your computer to the same LAN. Do not use the RJ-45 Jack on the front of the UC 110 Module. The UC110 can be accessed by using the IP Address of the KSU followed by Port Number 7070 Example: If your KSU is 192.168.1.123 then the UC110 will be found at http://192.168.1.123:7070...
- Page 2 Page 2 1. Click here... After you connect to the UC110, follow these instructions: Note: MAPI is here too... 2. Click here to download and install the VM Pro Client. It is used to program the VM Pro After you install the VM Pro Client, you can begin to program it or use the VM Pro Exercises Manual and learn the product.
- Page 3 LAN IP Address of the VM Most of the programming will be done using the VM Pro Client software. A quick test to see if the UC110 is working is to dial *17 (STAR 17) on a phone and see if the greeting answers you.
- Page 4 Page 4 Once you have made the INITIAL connection to the UC100 via the KSU's IP Address and Port 7070 with a browser, you can continue with the set up. The Logon is webcontrol The Password is web The UC100 needs a LAN IP Address to send out Emails and any other feature that require a network connection.
- Page 5 Page 5 Now the UC100 will have its own LAN IP Address. You will use this IP Address in the future to Service the UC110. To program the UC110 (VM Pro) you will use the VM Pro Client. 1. Click here to start the VM Pro Client...
- Page 6 Page 6 1. Select Online You will see a pop up like this: 2. Click OK Administrator For both... You will see a pop up like this: Administrator Administrator 1. Enter the IP Address You entered on Page 4...
